IV. Installation- Sealed Enclosures
1. Sealed enclosures provide excellent performance with Platinum Format
subwoofers. They are the simplest enclosures to design and build. We
recommend you choose a sealed design if you have not built subwoofer
enclosures before. Remember to glue and screw all joints, using
enough glue to make sure all joints are air tight. Loosely fill the
enclosure with fiberglass, poly-fill, or cotton damping material.
PS12 Internal Volume
1.3ft
Optimum
0.7ft
Minimum
PS10
0.75ft
Optimum
0.45ft
Minimum
Ultmate
Internal Volume(ft
Internal Volume(L)= (in Centimeters)Internal Width X Depth X Height
4
Recommended Sealed Enclosures
Recommended
3
/36.8L
3
/19.8L
3
/21.2L
3
/12.7L
Width
3
)= (in Inches)Internal Width X Depth X Height
Ultimate
Driver
Displacement
3
0.144ft /4.08L
3
0.144ft /4.08L
3
0.09ft /2.55L
3
0.09ft /2.55L
He
igh
t
1728
1000
® ®
Sound
Total Internal
Volume
3
1.444ft /40.88L
3
0.844ft /23.88L
3
0.84ft /23.75L
3
0.54ft /15.25L
Depth
