064.0019: Eglu Cube Fixings Pack
064.0019: Eglu Cube Fixings Pack
Side to Front Panel Bracket Side to Roof Panel Bracket
064.1017
x4
Partition Bracket
064.1103
x2
064.0045: Eglu Cube Frame Assembly Box C
Frame Right Side
064.0027
x1
Frame Front Brace
064.0028
x1
You will need...
· DE Was Sie benötigen... · FR Vous aurez besoin de... · NL U heeft nodig... · ES Was Sie benötigen... · IT Occorrente...
Back Door U Bracket
064.1023 064.1028
x6 x2
Locator Block M6x10mm Screw
064.1143 800.0197
x1 x48
Frame Left Side
064.0026
x1
Frame Rear Brace
064.1056
x1
Roof Joint Bracket
064.1155
x1
Frame Ladder
Ladder Friction Strips
064.0030
810.1040
x1
064.0037: Fixings Pack Box C
Tray Locking Clip Back Bar Bracket
064.1043
x1
Side Panel to Frame Bracket
064.1022
x4
x9
M6x16mm Screw
800.0037
x9
M6x10mm Screw
800.0197
x7
Wing Nut
800.0040
x13
064.1099
x2
