INSTRUCTIONS FOR USE
You can use the steam mop in version A or B.
Version A: Stand appliance
• For version A you use the foot.
• The foot has a locking mechanism so that
the steam mop can stand freely.
• You can attach the mop or the mop and the
carpet attachment to the foot. According to
requirements.
• The length of the telescopic pole is set
with the lock. Pay attention to the attached
symbols.
Version B: Hand appliance
• Press the button on the appliance to release
the telescopic pole.
• Attachments 8 to 12 ,14 and 16 can be
used with the hand appliance.
• These parts can be fitted to adapter 8.
• First fit the adapter onto the bushing on the
appliance.
The adapter can only fit in one position.
• You can now select and attach an accessory.
• The multi-purpose attachment 9 can be
combined with parts 11 or 16.
Release the attachments
• Parts 8 to 17 can be easily detached.
• Other parts, such as the foot, are secured to
the counterpart with a button.
• Press the button and pull the parts apart.

INITIAL OPERATION

Fill in Water
NOTE :
• The maximum filling capacity is 400 ml.
Use the measuring cup provided.
• Recommendation: Use distilled water to
prevent calcification.
CAUTION:
Do not use battery water, water from tumble
dryers or water with additives such as
cleaning agents, alcohol, fabric softener or
other chemicals. They could cause hazards
or damage to the appliance.
WARNING: Risk of injury!
1. Disconnect the mains plug from the wall
socket.
2. If the appliance is still warm, wait approx.
5 minutes until removing the lid.
3. The cap on the tank can be screwed on. Pay
attention to the attached symbols.
4. Fill water up to the maximum mark.
5. Close the tank.
Electrical Connection
• Before inserting the plug into the socket.
Make sure that the mains voltage to be used
matches that of the device.
You can find this information on the
nameplate.
• Connect the device to a duly installed
protective contact socket.

USING THE DEVICE

CAUTION:
• Prevent damage and ensure that the
appliance is also suitable for this surface!
• Test the cleaning action first on a concealed
area!
• Do not hold the steam nozzle for too long
and too close in one position.
1. Press the switch
2. The steam mop is ready for use after
approx. 30 seconds.
Filling the Water Tank during Operation
No steam will be discharged if the water tank
is empty. The water has to be filled up as
follows:
1. Press the switch
2. Remove the mains plug from the socket!
3. Fill water up to the maximum mark.
4. Connect the plug to the socket again and
switch the appliance on to continue operation.
When you have finished using the device
1. Press the switch .
2. Remove the mains plug from the socket!
3. Let the unit cool down completely.
4. Empty the water tank.
12
EN
