Manual RAC 02 CD & MP3-Player/Tuner (RDS) Status: September 2016 Please read carefully the instructions in this manual before use. Please keep this user manual nearby for anytime reference. If the following circumstances will occur, please immediately switch off the power and disconnect the power supply cord.
Seite 2
Front: Rear: SUPPLEMENTS: AM Antenna Set x 1 FM Antenna Wire x 1 AV Wire x 2 AC Power Cord INSTALLATION: 1. Connect AV Cord to OUTPUT Terminal. 2. Connect AC Power Cord in between Socket and AC power resource in AC 220V or Connect DC Power Cord in DC 24V Terminal.
AM / FM TUNER (RDS) OPERATION POWER : Power on and off BAND : Switch for AM or FM MO/ST : Switch for mono or stereo iPod / AUX IN : Connect iPod or other audio source Radio Playing Press " BAND ” to select FM 1,FM 2, or AM frequencies. The stations in the FM 1 or FM 2 are all the same.
Seite 4
Radio stations can assign different program types to their shows. These can be picked up by an RDS radio. Press PTY, LCD shows the radio program type, such as news, sports or drama. If the radio station does not assign the program type for the program, LCD shows “NO PTY”.
Seite 5
Anti Shock CD / USB & SD Card Reader FEATURES Offers USB, SD Card and CD playing function Format: MP3, WMA Accept the capacity of 128MB to 16G USB or SD Card CONTROLS: POWER ON / OFF 1. Turn on the Master Power 2.
Seite 6
function. PROG : To memorize the self-set tracks. 1. Normal music format of CD, USB, or SD Card : Press PROG. LCD display shows “PROGRAM” then use SKIP combinative buttons to − select the song and then press RAN / ENTER key to confirm Repeat above step to store more tracks.
Seite 7
CD player, Otherwise the unit could be damaged. ic audio GmbH • Boehringerstraße 14a • D-68307 Mannheim • Germany Fon: ++49 (0) 621 / 77096 -0 • Fax: ++49 (0) 621 / 77096 -26 • Email: info@ic-audio.com...
Seite 8
Bedienungsanleitung RAC 02 CD & MP3-Player/Tuner (RDS) Status: September 2016 Bitte lesen Sie diese Hinweise sorgfältig durch, bevor Sie das Gerät anschließen und betreiben. Halten Sie diese Bedienungsanleitung stets griffbereit, um jederzeit darauf zurück greifen zu können. Wenn folgende Umstände zutreffen, ist das Gerät sofort auszuschalten und der Netzstecker zu ziehen.
Seite 9
Vorderseite: Rückseite: Lieferumfang: AM-Antennen Set x 1 FM-Antennenkabel x 1 AV-Kabel x 2 AC Stromkabel Inbetriebnahme: Verbinden Sie das AV Kabel an die Ausgangsklemme. Schließen Sie das Netzkabel an die Steckdose an, oder nutzen den DC 24V Anschluss für Batteriebetrieb. Schließen Sie die AM FM Antenne an der Rückseite an.
Seite 10
AM / FM TUNER (RDS) Betrieb: POWER : Drücken Sie “ POWER ” um das Gerät anzuschalten Drücken Sie erneut “ POWER ” um das Gerät abzuschalten. BAND : Drücken Sie " BAND " um die gewünschte Frequenz zu wählen (AM / FM) MO/ST : Auswahl Mono- und Stereo-Modus iPod / AUX IN : Eingang für den Anschluss eines iPod oder einer anderen Audio-Quelle...
Seite 11
Senderspeicher Es stehen Ihnen 20 Speicherplätze zur Verfügung: FM 1 x 10 / FM 2 x 10 / AM x 10 − Wählen Sie den gewünschten Sender − Drücken Sie die Taste “ MEMORY “ − Drücken Sie die Taste “ MEMORY UP“ um den Speicherplatz zu wählen. Erneutes −...
Anti Shock CD / USB & SD Card Reader FEATURES USB, SD Card und CD-Wiedergabe Unterstütze Formate: MP3, WMA 128MB bis 16GB USB oder SD Card Bedienung: POWER ON / OFF ON / AN : Drücken Sie “Power” um das Gerät anzuschalten OFF / AUS:Drücken und halten Sie “Power”...
Seite 13
Erneutes Drücken der Taste, das LCD zeigt REPEAT FOLDER : : Repeat-Funktion für − alle Tracks in einem Ordner. Dreimaliges Drücken der Taste, das LCD zeigt REPEAT ALL : Repeat-Funktion für alle − Tracks Erneutes Drücken der Taste deaktiviert die Repeat-Funktion. PROG : Zum Speichern Ihrer gewünschten Wiedergabeliste.
Seite 14
Unsachgemäße Handhabung kann zu Beschädigungen des Laufwerks führen! Auch die Funktion des ganzen Gerätes kann so beeinträchtigt werden. ic audio GmbH • Boehringerstraße 14a • D-68307 Mannheim • Germany Fon: ++49 (0) 621 / 77096 -0 • Fax: ++49 (0) 621 / 77096 -26 • Email: info@ic-audio.com...
