Operation

When choosing a cable, please note that there are different types of HDMI
cables. In case of doubt, consult a professional for further information.
Use a high-speed HDMI cable to play back a 3D signal with a bandwidth of
more than 225 MHz or a resolution of 4K x 2K.
The product supports HDCP encryption and 3D playback.
If you connect two televisions, which each have a different max. resolution,
then the lower resolution is automatically displayed on both televisions.
For example: A television with 4K-resolution is connected to one output.
A television with 720p-resolution is connected to the other output. The
picture is displayed with a resolution of 720p on both televisions.
• Make sure all devices to be connected are switched off.
• Connect a playback device (e.g. BluRay player, DVD player, game console) with
the fixed installed HDMI cable.
• Connect up to two output devices (i.e. television, projector, monitor) to HDMI
OUTPUT 1 and HDMI OUTPUT 2 using suitable HDMI cables.
• Turn on all connected devices.
Normally the product is supplied with power from the HDMI input source,
so that it is not necessary to use the enclosed USB power cable.
If the HDMI input source does not supply sufficient power, connect the
low-voltage round plug of the USB power cable with the power connection.
Then connect the USB plug of the USB power cable with an unused USB
port of a computer or a suitable USB power adapter (output 5 V/DC,
500 mA).
LED signals
LED Signal
OUTPUT 2 Lights up blue when
• the product is supplied with power,
OUTPUT 1
• an output device is connected and
• the HDMI signal is displayed on the output device.
INPUT Lights up blue when
• the product is supplied with power,
• a playback device is connected and
• the playback device is turned on.
Cleaning and care
• Each time before cleaning, disconnect the product from all connected devices.
• Under no circumstances use aggressive cleanings agents, cleaning alcohol or other
chemical solutions since these can penetrate the housing or impair functionality.
• There are no components located inside the product you need to maintain. Never
open/dismantle the product.
• Clean the product with a dry, fibre-free cloth.
• You can easily remove dust using a long-haired, soft and clean brush.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product in
accordance with applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of
the environment.
Technical data
Operating voltage ................... 5 V/DC
Power consumption ............... max. 500 mA
Input........................................ 1 x HDMI
Output ..................................... 2 x HDMI
Frequency range .................... 25 - 300 MHz
Supported resolutions ............. 480i~1080p@50/60 Hz
1080p@24/50/60 Hz
VGA~UXGA, 4K 2K@30 Hz
3D support .............................. up to 1080p, 60 Hz
Supported standards .............. HDCP 1.3
Standard Audio
DSD Audio
HD (HBR) Audio
Video bandwidth ..................... 340 MHz / 10.2 Gbps
Operating conditions ............... 0 to +40 ºC, 20 – 90 % RH (non condensing)
Storage conditions .................. -20 to +60 ºC, 20 – 90 % RH (non condensing)
Dimensions (W x H x D) ......... 80 x 13 x 57 mm
Weight .................................... 84 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represents the technical status at the time of printing.
Copyright 2016 by Conrad Electronic SE. 1603385_V1_1017_02_JC_m_en
