General instructions for connecting HELIX
speaker systems
We strongly recommend that you operate the com-
plete audio system at low volume before final in-
stallation. This will allow a trial listening test before
securing the loudspeakers into their mounting loca-
tions.
Make sure that all speaker wiring is fully protected
from cutting or wear at sharp edges. This can lead
into a short circuit which might damage your head
unit, amplifier and/or speaker system.
Make sure that all speaker wires have sufficient
length in order to reach the speaker terminals with-
out stress on the wire or connectors.
Features
Component systems
• Woofer with very stiff and non-resonating
woofer cones made from woven fiberglass
• Specially shaped rubber surround for larger
effective cone area and increased maximum
excursion
• 1 inch / 25 mm silk dome tweeter with neo-
dymium magnet for brilliant and smooth treble
response
• Tweeters are 25° tiltable for perfect alignment
with listening position
• Individual HELIX design basket with addition-
al ventilation holes for better voice coil cooling
and high power handling
• Complex, separate crossover with 6/12 dB
slope, bandstop filter, tweeter protection and
adjustable tweeter level
• Grille included
8
General instructions for mounting HELIX speak-
er systems
Once you have tested the complete speaker system
and have confirmed correct operation, turn off the
audio system and prepare the loudspeaker for final
mounting.
1. Place the loudspeaker in the mounting posi-
tion as shown in the illustration "Mounting the
woofer".
2. Fix the speaker with its mounting ring in its in-
stallation place and check if all screws are in
the right position to the fixing holes. Use the
included screw clips to secure the screws.
Tighten all screws evenly.
3. Attach the mesh to the mounting ring.
Coaxial systems
• Woofer with very stiff and non-resonating
cones made from woven fiberglass
• Specially shaped rubber surround for larger
effective cone area and increased maximum
excursion
• 0.75 inch / 19 mm silk dome tweeter with
neodymium magnet for brilliant and smooth
treble response
• Tweeters are 360° pivotable and 25° tiltable
for perfect alignment with listening position
(E 5X.2 / E 6X.2)
• Individual HELIX design basket with addition-
al ventilation holes for better voice coil cooling
and high power handling
• Separate inline crossover with integrated
tweeter protection
• Grille included
