ASSEMBLY
GB
Step 3
Put rubber rope through the loop of jumping mat, connect it onto the frame tube Repeat this work until all tops of leg tubes
are connected with rubber ropes, see the above pictures (Please notice the numbers of loops between two leg tubes is 9)
Then connect all rubber ropes onto the frame tube (Pic 3a to 3d)
Pic. 3a Pic. 3b Pic. 3c Pic. 3d
Step 4
Twist the lower handle into the trampoline like the above picture, then insert the upper handle into the lower handle And
you can adjust the height of handle by turning the screw (Pic 4a and 4b)
Pic. 4a Pic. 4b
10
