Transmitter Preparation
調整遙控器
A new Ni-MH battery must be charged before it is used.Refer to the charger instruction manual for charging.
在使用之前，一個新電池必須先充電。詳情請參考充電器說明書。
Set up the radio control system as indicated below。
如下圖所示安裝接收機控制系統
Battery
電池
2
11
5
DIGITAL
PROPORTIONAL
RADIO CONTROL
SYSTEM
6
ON
5
8
10
OFF
1
Start
Finish
Tools required
組裝需要的工具
Needie Nose Pllers
尖嘴鉗
Ball differential Grease(Clear)
差速滾珠油(清澈)
Molybdenum Grease(Black)
鉬油(黑)
Hex Wrench
Hex Wrench
十字套筒
六角扳手
3
8
發送機
6
ON
10
OFF
Install batteries.(Transmitter)
1
Extend the antenna.(Transmitter)
2
Connect the battery
3
Extend the antenna.(Reveiver)
4
Center the trims.
5
Switch on.(Transmitter)
6
Switch on.(Reveiver)
7
Make sure the servos are in command.
8
Switch off.(Reveiver)
9
Switch off.(Transmitter)
10
Retract the antenna(Transmitter)
11
Awi
錐
SP KINFE EDGE REAMER
刀刃 絞刀
No need to pre-drill precise holes
(1mm to 15mm)can be drilled
可以對預鑽的孔準確的鑽深
1mm-15mm,不需要穿透
Transmitter
Servo
伺服機
Grease
潤滑油
Receiver
接收 機
開始
1
安裝電池(發送機)
2
拉出天線(發送機)
3
連接電池
4
拉出天線(接收機)
中心對整齊
5
開關(發送機)
6
7
開關(接收機)
8
確定控制伺服機
結束
9
關閉開關(接收機)
10
關閉開關(發送機)
11
收回天線(發送機)
Screw Cement
Instant Glue
瞬間膠水
螺絲膠水
Wire Cutters
ROUND CUTTER&SANDER
鋼絲鉗
剪刀&挫刀
Sharp Hobby knife
美工刀
For trimming bodies!
用於修剪車殼！
Motor
馬達
Electronic Speed
Controller
電子加速控制器
7
9
Switch
開關
4
