Installation instructions

Monitor
To camera input
Connect DVR to
MONITOR (cable not
included)
SEC-DVR504

User instructions

To get you started, the following chapters describe some of the features and functions of the DVR.
Please refer to the extensive English manual for further details about the DVR. For system settings, it is
recommended to use the mouse.
The DVR switches on automatically when the AC/DC power supply is connected to the DVR and a
power outlet.
During configuration, press

Login:

In live view, press
the mouse in live view to display the toolbar. The login window
will appear if the password is enabled. You can enter a user
name and password to login.
1. The default password for Admin is 888888 and the default
password for user1 is 666666.
2. The device ID is used for connecting the IE interface. For the
detailed operation, please refer to the extensive manual.
Note: logging into the DVR is necessary to enter the menu and change the settings.
To 12 V DC input
Divider cable
with 5x DC
Connect divider cable to power supply
AC/DC power
supply
To 220 V AC power outlet
to restore the default setting. Press
twice or double-click the right key of
18 m connection cable
Up to a total of 4 camera inputs
output
9
4x
to save the settings.
SEC-CAM25
or
SEC-CAM355
