POWER PLUG
CHANNEL 2:
2
XLR OUTPUT BALANCED
3
6.3 MM JACK OUTPUT BALANCED
4
6.3 MM JACK INPUT BALANCED
5
XLR INPUT BALANCED
2 3 4 5
CHANNEL 1:
6
XLR OUTPUT BALANCED
7
6.3 MM JACK OUTPUT BALANCED
8
6.3 MM JACK INPUT BALANCED
9
XLR INPUT BALANCED
EQ215
GRAPHIC EQUALIZER

BACK PANEL:

6 7 8 9
