User Manual
Introduction
The LINDY USB 3.0 Active Extension Pro System enables you to extend your USB 3.0 devices
by up to 38m* with USB 3.0 SuperSpeed performance!
The USB 3.0 Active Extension Pro System consists of three different units (each sold
seperately):
USB 3.0 Active Extension Pro 8m (LINDY Number 43158)
USB 3.0 Active Extension Hub Pro 10m (LINDY Number 43159)
USB 3.0 Active Extension Pro 10m (LINDY Number 43157)
*In some cases (depending on PCB, USB 3.0 controller etc.) this may be limited to 18m
Instructions
Please Note: Only the USB 3.0 Active Extension Pro 8m can be connected directly to your
computer.
If you are creating an extension using multiple units from the Extension Pro System then the
first unit must always be the USB 3.0 Active Extension Pro 8m (Lindy Number 43158).
Once the first cable has been connected you can then cascade up to a further three cables to
achieve a maximum distance of 38m. The final part of the extension can be any of the three
parts of the Extension Pro System.
If you need to extend multiple devices or if you connect a USB device with high power
requirement, then you should use the 10m Hub Pro unit with it's power supply as the final part
of the extension.
Example Set-up:
8m Extension Pro
Computer
If you connect your USB device(s) to the final part of the extension using a standard USB 3.0
cable, please ensure that the cable used is no longer than 3m.
43158
8m Extension Pro 43158 /
10m Extension Pro 43157 /
10m Extension Hub Pro 43159
English
