2. EXPLODED VIEW
21
10
19
23
1
11
4
1. Chassis
2. Left Side Panel
3. Side Window
12
22
4. Right Side Panel
5. Right Side Mesh Cover
6. Front Panel
2
7. Front Panel Door
5
8. ODD Cover
20
3
9. Front Cover Dust Filter
10. Top Panel Mesh Cover
11. Top Panel
13
12. Reservoir Bracket
8
13. Reservoir Bracket Cover
7
9
14. Bottom Radiator Bracket
15. Bottom Dust Filters
16. Tool-less ODD
17. Phanteks Logo plate
18. Front Mesh Cover
19. Hard Drive Cage
16
18
20. Hard Drive Stand
21. SSD Bracket
15
17
6
14
22. Pump Bracket
23. Side Radiator Bracket
6
