GE AS363 Installationsanweisung

E E N N
D D E E
T T O O N N E E T T O O N N E E T T Y Y P P E E
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
GE Security, Kelvinstraat 7, NL- 6003DH Weert, The Netherlands.
Phone +31 495 45 67 35 Fax: +31 495 55 00 42
Installation Instructions
F F R R
N N L L
T T O O N N E E D D E E S S C C R R I I P P T T I I O O N N / / A A P P P P L L I I C C A A T T I I O O N N
970Hz
800Hz/970Hz @ 2Hz
800Hz – 970Hz @ 1Hz
970Hz 1s OFF/1s ON
970Hz, 0.5s/ 630Hz, 0.5s
554Hz, 0.1s/ 440Hz, 0.4s (AFNOR NF S 32 001 )
500 – 1200Hz, 3.5s/ 0.5s OFF (NEN 2575:2000)
420Hz 0.625s ON/0.625s OFF (Australia AS1670 Alert tone)
500 – 1200Hz, 0.5s/ 0.5s OFF x 3/1.5s OFF ( AS1670 Evacuation)
550Hz/440Hz @ 0.5Hz
970Hz, 0.5s ON/0.5s OFF x 3/ 1.5s OFF (ISO 8201 )
2850Hz, 0.5s ON/0.5s OFF x 3/1.5s OFF (ISO 8201)
1200Hz – 500Hz @ 1Hz (DIN 33 404)
400Hz
550Hz, 0.7s/1000Hz, 0.33s
1500Hz – 2700Hz @ 3Hz
750Hz
2400Hz
660Hz
660Hz 1.8s ON/1.8s OFF
660Hz 0.15s ON/0.15s OFF
510Hz, 0.25s/ 610Hz, 0.25s
800/1000Hz 0.5s each (1Hz)
250Hz – 1200Hz @ 12Hz
500Hz – 1200Hz @ 0.33Hz
2400Hz – 2900Hz @ 9Hz
2400Hz – 2900Hz @ 3Hz
800Hz – 970Hz @ 100Hz
800Hz – 970Hz @ 9Hz
800Hz – 970Hz @ 3Hz
800Hz, 0.25s ON/1s OFF
500Hz – 1200Hz, 3.75s/0.25s OFF (AS2220)
Fig. 1
E E S S
P P T T
EN54-3
Technical Data Document 18-186213
Fire Alarm Device - Sounder
Type A: For indoor use
(Shallow Base)
Type B: For outdoor use
(Deep Base)
Copyright © 2007GE Security B.V.. All Rights Reserved
AS363 & AS364 Sounder Range
I I T T S S E E
P P L L
D D I I P P S S W W I I T T C C H H 2 2 n n d d
O - O - O - O - O 18
O - O - O - O - I 1
O - O - O - I - O 1
O - O - O - I - I 5
O - O - I - O - O 1
O - O - I - O - I 1
O - O - I - I - O 1
O - O - I - I - I 9
O - I - O - O - O 1
O - I - O - O - I 19
O - I - O - I - O 1
O - I - O - I - I 1
O - I - I - O - O 1
O - I - I - O - I 18
O - I - I - I - O 1
O - I - I - I - I 1
I - O - O - O - O 1
I - O - O - O - I 1
I - O - O - I - O 18
I - O - O - I - I 19
I - O - I - O - O 19
I - O - I - O - I 1
I - O - I - I - O 1
I - O - I - I - I 1
I - I - O - O - O 1
I - I - O - O - I 18
I - I - O - I - O 18
I - I - O - I - I 1
I - I - I - O - O 1
I - I - I - O - I 1
I - I - I - I - O 1
I - I - I - I - I 8
AS363: 0832-CPD-0556
AS364: 0832-CPD-0557
AS363W 0832-CPD-0558
AS364W 0832-CPD-0559
Revision 1.1 (July 2007) 18-186755
http://www.gesecurity.eu
D D K K
d d B B A A @ @ 1 1 m m m m A A
99 17
100 16
100 16
99 10
99 15
97 09
99 12
96 5
98 6
97 10
98 8
94 17
99 13
95 9
98 13
104 30
99 14
106 41
96 13
96 8
96 7
98 11
100 17
98 9
99 14
101 36
104 36
100 16
99 16
100 6
99 4
99 13
0832
06
