Lindy Combo 200 Benutzerhandbuch

Cat.5 KVM Extender Combo 200
User Manual
Benutzerhandbuch
Manuale d'uso
Manuel d'utilisateur
Remote
Operator's PC
Receiver
LINDY No. 39398
www.lindy.com
Tested to Comply with FCC Standards
For Home and Office Use!
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (May 2010)
Features
• Provides a real-time, convenient and password secure method of
remotely locating PCs or servers without compromising convenience
and control
• Distances of up to 200m supported between local and remote units
• Local Transmitter unit features a built-in KVM Switch - allowing local as
well as remote console access
• Remote Receiver unit features a built-in KVM Switch – allowing local
and remote access
• Supports USB as well as PS/2 standard keyboard and mouse signals
in any combination – for devices and for output to the systems
• High-resolution video support: typically 1600 x 1200 or 1680 x 1050 for
up to 200m – Use monitors with the same aspect ratio on local and
remote console
• Adjustable OSD controlled VGA amplification and focus tuning control
as well as electronic RGB skew compensation to improve video quality
• Easy, user-friendly installation - no software required
Packaging Contents
• Local Transmitter unit
• Remote Receiver unit
• 5V DC, ~1A Power Adapter (x2 – for both units, with multi country
adapters for EUR, UK, US and AUS/China)
• 2 x KVM combo cables 3-in-1 with additional USB to PS/2 adapter to
connect the local computer and the remote system to the
transmitter/receiver units
• This manual
Combo 200
English
Deutsch
Italiano
Français
Local
Console
Transmitter
Up to 200m
KVM Switch / or PC
English
English
Overview
Thank you for purchasing the LINDY KVM Extender Combo 200. The Thank you for purchasing the LINDY KVM Extender
KVM Extender Combo 200 allows you to control your PC, server or KVM allows you to control your PC, server or KVM
switch from a keyboard, mouse and monitor at a resolution of 1600 x switch from a keyboard, mouse and monitor
1200 or 1680 x 1050 at distances of up to approximately 200 metres (600
feet) away using low cost UTP CAT5 or higher cable.
The KVM Extender Combo 200 consists of a Transmitter (Local) unit and consists of a Transmitter (Local) unit and
a Receiver (Remote) unit. The Transmitter connects to a computer or a Receiver (Remote) unit. The Transmitter connects to
KVM switch. The Receiver unit is located at a remote location and KVM switch. The Receiver unit is located at a remote location and
connects to a keyboard, monitor and mouse console offering a KVM connects to a keyboard, monitor and mouse console
switch to switch between a local connected computer and the remote switch to switch between a local connected computer and the remote
system.
The KVM Extender Combo 200 converts the VGA
into a signal that can be transmitted over inexpensive CAT5 Ethernet into a signal that can be transmitted over inexpensive CAT5 Ethernet
cable. The extender accepts USB as well as PS/2 keyboard and mouse The extender accepts USB as well as PS/2 keyboard and mouse
signals in any combination and can also output it in any combination. signals in any combination and can also output it in any combination.
However, please note that for USB only HID devices like mice and te that for USB only HID devices like mice and
keyboards are supported. The extender only supports standard signals keyboards are supported. The extender only supports standard signals
for mice with up to 5 buttons as well as standard keyboard functions. for mice with up to 5 buttons as well as standard keyboard functions.
The VGA signal is separated into the RGB components and sent over The VGA signal is separated into the RGB components and sent over
individual twisted pairs of the RJ45 cable. The extender features an OSD ividual twisted pairs of the RJ45 cable. The extender features an OSD
adjustable electronic skew compensation and amplification circuit to adjustable electronic skew compensation and amplification circuit to
adjust the video quality to the connection cable to provide optimum video adjust the video quality to the connection cable to provide optimum video
quality.
The KVM Extender Combo 200 is idea
system administrators - a workstation can be connected to the Receiver a workstation can be connected to the Receiver
unit allowing the operator to work on his computer or remotely on the unit allowing the operator to work on his computer or remotely on the
KVM switch. Additionally, a local console can be connected to the KVM switch. Additionally, a local console can be connected to the
Transmitter unit for direct access to the KVM switch. Both local and irect access to the KVM switch. Both local and
remote consoles can access the servers connected to the KVM switch remote consoles can access the servers connected to the KVM switch
simultaneously, governed by a short timeout. simultaneously, governed by a short timeout.
Installation and Use
For connecting the local and remote units Category 5e/6 UTP cable
provides the best results. Using higher quality shielded STP/FTP cable
may result in a degraded video signal and shorter transmission
distances.
See www.lindy.com for our range of appropriate cables.
Make sure all of your computers and peripherals are switched OFF
before proceeding with the installation.
Your monitor at the remote Receiver should at least support the
resolution as provided by the remote system.
Receiver Unit, Model 39398
Connect your keyboard, mouse and monitor to the Console ports on the
Receiver unit. You may either use USB or PS/2 mouse and keyboard.
Use the supplied 3-in-1 KVM cable to connect to your computer. Do NOT
connect USB AND PS/2 at the same time! If you want to connect via
USB use the VGA and USB connector only! If you want to connect via
PS/2 use the supplied USB to PS/2 adapter for the USB cable end on the
3-in-1 cable. Connect the Receiver's power supply and power on your
computer and monitor and check if the Receiver works correctly.
Connect the CAT5/5e/6 RJ45 cable to the RJ45 port. Do NOT use a
LAN/Ethernet connection. You must always use a dedicated direct
cable! Adding any additional connections in-between like wall
outlets etc. will result in reduced video quality!
Transmitter Unit, Model 39398
Connect the CAT5/5e/6 RJ45 cable to the RJ45 port.
Connect your console keyboard, mouse and monitor to the ports on the
Transmitter unit labelled Console. Use the other 3-in-1 cable to connect
to the keyboard, video and mouse ports on the KVM switch or on the
system. Regard the USB-PS/2 connectivity remarks as mentioned above!
Connect the Transmitter's power supply and power on your system and
monitor and check if the Transmitter is working correctly.
Now go to the Receiver and switch it to use the remote Cat.5
connection either by pressing the switch button or by typing in the
hotkey command CAPS + CAPS + left or right cursor key. Your
video image may be blurred in the beginning. It must now be tuned
via the OSD (On Screen Display) adjustment.
English
to approximately 200 metres (600
or higher cable.
s the VGA, USB and PS/2 signals
is ideal for network managers and
English
