ISHIMA ultrex Anleitung Seite 26

26
Picture Item Nr
ISH-021-001 Chassis
Front Bottom Plate + Rear Bottom
Plate + Rear Shock Tower Mount +
ISH-021-002
Front Suspension Mount +
Front Suspension Pin Brace Pad
Front Top Mount + Servo Arm + Servo
ISH-021-003
Mount
ISH-021-004 Front Top Steering Mount
ISH-021-005 Diff Gear Housing
Diff.Main Gear + Idler Gear + Diff.
Pinion Gear + Diff. Large Bevel Gears
ISH-021-006
+ Diff. Small Bevel Gears + Diff. Inner
Mount
ISH-021-007 Front Bumper + Motor Guard
Gear Cover + Access Plug ( Silicone
ISH-021-008
Rubber)
Rear Suspension Pivot Block Set
ISH-021-009
(A pair)
Battery Holder + Lock Pins + Load
ISH-021-010 Spring + Mount + Cap Head Screw
2*8mm
Front Shock Tower + Rear Shock
ISH-021-011
Tower
Steering Mount Assembly + Steering
ISH-021-012
Ackerman Plate
ISH-021-013 Front Suspension Arms (Left/right)
Description + Content ULTREX ROCAT
OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK
OK
OK OK
OK
