Picture size and projection distance chart
Side View
Screen
H2 Lens center
L
NORMAL Mode (4:3)
Picture (Screen) size
χ
Diag. [ ] Width Height
150'' (381 cm) 305 cm (120'') 229 cm (90'')
100'' (254 cm) 203 cm (80'') 152 cm (60'')
84'' (213 cm) 171 cm (67'') 128 cm (50'')
80'' (203 cm) 163 cm (64'') 122 cm (48'')
STRETCH Mode (16:9)
Picture (Screen) size
χ
Diag. [ ] Width Height
133'' (338 cm) 294 cm (116'') 166 cm (65'')
106'' (269 cm) 235 cm (92'') 132 cm (52'')
100'' (254 cm) 221 cm (87'') 125 cm (49'')
92'' (234 cm) 204 cm (80'') 115 cm (45'')
84'' (213 cm) 186 cm (73'') 105 cm (41'')
72'' (183 cm) 159 cm (63'') 90 cm (35'')
Note
• There may be an error of ±3% in the above values.
• Values with a minus (–) sign indicate the distance of the lens center below the bottom of the
image.
While the image is set to the upper
left or upper right of the adjustable
range, the corner of the image is
masked with a shadow.
Width of the image × 11%
1
AN-PH10EX_Lens_E.p65
Top View
Screen
Lens center
Lower lens shift
position
(High mount setup)
Upper lens shift
position
(Desktop setup)
Distance from the lens center to the
Projection distance
bottom of the image [H]
[L] Lower [H1]
2.4 m (8' 0") (–45")
–114.3 cm
1.6 m (5' 4") –76.2 cm (–30")
1.4 m (4' 6") –64.0 cm (–25 13 / ")
64
1.3 m (4' 3") (–24")
–61.0 cm
Distance from the lens center to the
Projection distance
bottom of the image [H]
[L] Lower [H1]
(7' 9")
2.4 m –82.8 cm (–32 39 / ")
64
1.9 m (6' 2") –66.0 cm (–25 63 / ")
64
(5' 10")
1.8 m –62.3 cm (–24 33 / ")
64
1.6 m (5' 4") –57.3 cm (–22 35 / ")
64
(4' 11")
1.5 m –52.3 cm (–20 19 / ")
32
1.3 m (4' 2") –44.8 cm (–17 21 / ")
32
1
Lens center
Leftmost lens shift
Center of position
screen
Rightmost lens shift
position
Lens center
Distance from the
lens center to the
bottom of the image
Upper [H2] [W]
–73.2 cm (–28 51 / ") ±33.5 cm (13 13 /
64 64
–48.8 cm (–19 13 / ") ±22.4 cm (8 51 /
64 64
–41.0 cm (–16 1 / ") ±18.8 cm (7 25 /
8 64
–39.0 cm (–15 23 / ") ±17.9 cm (7 3 /
64 64
Distance from the
lens center to the
bottom of the image
Upper [H2] [W]
–43.1 cm (–16 61 / ") ±32.4 cm (12 3 / ")
64 4
–34.3 cm (–13 33 / ") ±25.8 cm (10 5 / ")
64 32
–32.4 cm (–12 3 / ") ±24.4 cm (9 19 / ")
4 32
–29.8 cm (–11 47 / ") ±22.4 cm (8 53 / ")
64 64
–27.2 cm (–10 45 / ") ±20.5 cm (8 3 / ")
64 64
–23.3 cm (–9 11 / ") ±17.5 cm (6 29 / ")
64 32
Height of the image × 18%
The position of the image when
the vertical position of the image
is center and the horizontal
position is the lowest
Image center
04.12.24, 3:06 PM
The formula for picture
size and projection
distance
χ : Picture size (diag.) (in)
")
[m/cm]
L (m) = 0.01626 χ
")
H1 (cm) = –0.762 χ
") H2 (cm) = –0.48768 χ
W (cm) = ±0.22352 χ
")
[Feet/inches]
L (ft) = 0.01626 χ / 0.3048
H1 (in) = –0.762 χ / 2.54
H2 (in) = –0.48768 χ / 2.54
W (in) = ±0.22352 χ / 2.54
The formula for picture
size and projection
distance
χ : Picture size (diag.) (in)
[m/cm]
L (m) = 0.01771 χ
H1 (cm) = –0.62263 χ
H2 (cm) = –0.32377 χ
W (cm) = ±0.24352 χ
[Feet/inches]
L (ft) = 0.01771 χ / 0.3048
H1 (in) = –0.62263 χ / 2.54
H2 (in) = –0.32377 χ / 2.54
W (in) = ±0.24352 χ / 2.54
