Technical data
Type
Rated voltage
Nominal current
Performance
Stroke
Runtime
Service life
Duty cycle
Housing
Ingress protection
Temp. range
Connection
Forces
-
Locking direction
-
Unlocking direction
-
Breakaway force
in unlocking direction
* Programmable with software SW-BSY+
** Adjustable via DIP switch
Plug connection
Cable tie
< optional >
99.824.16 2.2/09/13
VLD 51/038-BSY+
24 VDC ± 20 %
1 A
24 VA
/
19 or 38 mm * **
approx. 4,5 or 9 s *
> 10.000 double strokes
30 % (with cycle time 10 minutes)
stainless steel (V2A)
IP 50
-5°C...+50°C
2,5 m silicone cable
max. 500 N *
max. 600 N *
max. 1000 N
Clamping range :
0,2 ... 1,0 mm²
(solid or flexible)
(WH)
white
(BN)
brown
(OG)
orange
(YE)
yellow
(GN)
green
(PK)
pink
(GY)
grey
L
oop through terminals
max. 60 V / 6 A
English
1
2
3
4
5
6
7
8
9 10 11 12
1 2 3 4 5 6
7 8 9 10 11 12
7/20
VLD 51/038-BSY+
