Bedienungsanleitung 1. Merkmale Die Türsprechanlage ist speziell für ein Gebäude mit einer oder zwei Familien ausgelegt, das Ihnen den kombinierten Nutzen von Sicherheit und Komfort bietet. Es ist sehr gee- ignet für Villa, Einzelhaus, Hotel, Büro, usw. 2. Packungsinhalt • Innengerät x2 •...
Bedienungsanleitung 4. Montage A: Innengerät 1. Bohren Sie vier passende Löcher in die Wand. Befestigen Sie die Halterung mit Schrauben an der Wand und führen Sie die Kabel durch das mittlere Loch der Halterung. Nach dem Anschließen der Kabel alle Schrauben der Halterung fest anziehen. 2.
Seite 6
Bedienungsanleitung Anschlussanleitung 1. Verbinden Sie die Anschlussklemme 1 der beiden Innengeräte mit der Anschlus- sklemme 1 der Außeneinheit. 2. Verbinden Sie die Anschlussklemme 2 der beiden Innengeräte mit der Anschlus- sklemme 2 und 3 der Außeneinheit. 3. Verbinden Sie S1 & S2 der beiden Innengeräte mit dem Elektrischen Schloss. 6.
Seite 7
Bedienungsanleitung Innengerät 1) Telefonhörer 2) Taste entriegeln 3) Anschlussklemme für Elektrisches Schloss 4) Anschlussklemme für Außeneinheit...
Bedienungsanleitung 7. Technische Daten • Netzgerät Eingangsspannung: AC 100-240 V = 50/60 Hz • Netzgerät Ausgangsspannung: DC 12 V = 1000 mA • Reichweite: bis zu 450 m • Betriebstemperatur: -20°C ~ +40°C Die Spezifikationen können ohne Ankündigung geändert werden.
Owner’s manual 1. Features The doorphone is specially designed for a building containing one or two families, giving you the combined benefit of security and convenience. It is very suitable for villa, single house, hotel, office, etc. 2. Package contents •...
Owner’s manual 4. Installation A: Installation of indoor unit 1. Drill four proper holes in the wall. Fix the bracket on the wall with screws and pass the wiring through the middle hole of the bracket. After the connection, reinforce the bracket with screws.
Seite 12
Owner’s manual Wiring instruction 1. Connect the connection terminal 1 of the two indoor units with the connection termi- nal 1 of outdoor unit. 2. Connect the connection terminal 2 of the two indoor units with the connection termi- nal 2 & 3 of outdoor unit respectively. 3.
Seite 13
Owner’s manual Indoor unit 1) Receiver 2) Unlock button 3) Connection terminal for unlocking 4) Connection terminal for outdoor unit...
Owner’s manual 7. Technical parameter • Adapter Input Voltage: AC 100-240V = 50/60 Hz • Adapter output voltage: DC 12V = 1000 mA • Working distance: up to 450 m • Working temperature: -20°C ~ +40°C Specifications are subject to change without notice.
Instrukcja obsługi 1. Cechy Domofon jest specjalnie zaprojektowany dla budynku, w którym mieszka jedna lub dwie rodziny (w zestawie znajdują się 2 jednostki wewnętrzne), co daje podwójną korzyść: bezpieczeństwo i wygodę. Domofon może być również zastosowany w hotelach, skle- pach, magazynach, biurach itp. Uwaga: Urządzenie współpracuje tylko z zamkami z pamięcią.
Seite 16
Instrukcja obsługi 4. Instalacja A: Instalacja jednostki wewnętrznej 1. Należy wywiercić 4 otwory w ścianie do zamocowania uchwytu. Następnie należy przełożyć przewody poprzez środkowy otwór uchwytu i przykręcić uchwyt do ściany. 2. Przewody połączeniowe należy podłączyć zgodnie ze schematem (rozdział 5 instruk- cji).
Instrukcja obsługi Sposób podłączenia 1. Należy podłączyć styki 1 z dwóch jednostek wewnętrznych do zacisku 1 jednostki zewnętrznej. 2. Należy podłączyć styki 2 z dwóch jednostek wewnętrznych odpowiednio do zaci- sków 2 i 3 jednostki zewnętrznej. 3. Styki S1 i S2 jednostek wewnętrznych, należy podłączyć odpowiednio do jednego lub dwóch zamków (w zależności od wybranego wariantu).
Seite 19
Instrukcja obsługi Jednostka wewnętrzna 1) Słuchawka 2) Przycisk otwierania 3) Podłączenie zamka 4) Podłączenie jednostki zewnętrznej...
Instrukcja obsługi 7. Specyfikacja techniczna • Napięcie wejściowe zasilacza: AC 100-240 V = 50/60 Hz • Napięcie wyjściowe zasilacza: DC 12 V = 1000 mA • Zasięg: do 450 m • Temperatura pracy: -20°C ~ +40°C Specyfikacja produktu może ulec zmianie bez powiadomienia.
Manual de utilizare 1. Caracteristici Interfonul este special conceput pentru o cladire in care locuiesc mai multe familii, oferindu-va avantajul sigurantei si confortului. Interfonul este potrivit pentru a fi utilizat in vile, hoteluri, birouri, etc. 2. Continutul pachetului • Unitate interna x2 •...
Seite 22
Manual de utilizare 4. Instalare A: Unitate interna 1. Efectuati patru gauri in perete. Fixati suportul pe perete cu suruburi si treceti cablurile prin gaura situata in mijlocul suportului. Dupa conexiune, fixati suportul cu suruburi. 2. Asigurati-va ca ati conectat cablurile la interfon asa cum este descris in imaginea de mai jos.
Manual de utilizare 5. Schema de conectare Optiunea 1 Optiunea 2...
Seite 24
Manual de utilizare Instructiuni de cablare 1. Conectati terminalul de conectare 1 ale celor doua unitati de interior cu terminalul de conectare 1 al unitatii exterioare. 2. Conectati terminalul de conectare 2 ale celor doua unitati de interior cu terminalul de conectare 2 &...
Seite 25
Manual de utilizare Unitate de interior 1. Receptor 2. Buton deblocare 3. Terminal conexiune pentru deblocare 4. Terminal conexiune pentru unitatea externa...
Seite 26
Manual de utilizare 7. Specificatii • Tensiune de intrare adaptor: AC 100-240 V = 50/60 Hz • Tensiune de iesire adaptor: DC 12 V = 1000 mA • Distanta de functionare: pana la 450 m • Temperatura de functionare: -20°C ~ +40°C Specificatiile sunt supuse schimbarilor fara notificare prealabila.
