TROUBLESHOOTING
Installation Installation
1.Take off the back panel and mounting panel
The handle is hard to rotate
2.Check if the lC wire is installed correctly.(Refer to the step " install the back panel ")
1.Before installation, restore the lock
2.Please make sure the lock is installed correctly.
Fail to programming the lock
3.Please install fresh batteries and make sure the cable is connected correctly.
Operation
Question
The batteries are getting low. Please replace with 4*AA new batteriesfor the best
The keypad is keeping flashing
performance(Alkaline batteries, do not use recharge batteries)
1.Check if the batteries are new.
keypad do not respond
2.Check if the lC wire is installed corectlv. (refer to the step"Install the Back Panel")
Press the reset button on the circuit board to erase all codes. Once the resetting
Forgot master code/Default
work is complete, all passcodes will be erased and the proguamming code will
programming code is incorrect.
return to the default programming code 123456.
Passage Mode : ( the passage mode can turn off automatic locking)
This feature is optional and can be turned off.(Under auto-mode with
lock unlocking, press 123+
green light flashes with voice prompt successful.)
Initialization
lock unlocking
setting
Attention:
To keep it in passage mode, don't input password to unlock. Once password
entered to unlock, passage mode will be turned off accordingly.
FEATURES
•Two ways to access: code and key .
•Low power consumption,4 AA batteries can work for 1 year or 5000 times.
•Backlit keypad for use in low light environments.
•100pcs common user codes, 50pcs temporary codes.
•Built-in disguise feature to protect your codes from prying eyes.
•Low battery "red flash" warning indication.
INDICATOR LIGHT SIGNALS
•Green:
A correct code was entered.
•Blue:
Programming in progress, blue light flashes for 1s.
•Red:
1.An incorrect code was entered
2.A Programming error.
3. low battery warning
HOW TO RESET
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to tr y to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to
operate this equipment.RF Exposure Information
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
Suggested Action
Suggested Action
to set passage mode on.press 123+
123
Reset Button
After restore factory, change the master passcode as soon as
posible! because the default master code can unlock the
door easily.
Delete all user codes, including master code:
•Use a screwdriver to removethe interior assembly.
•Press and hold the reset buttonfor 5 seconds until
voice prompt & blue light flashes.
•Enter"000+ " ,voice prompt andthe green light
flashes means reset successfully.
SETTING DEFINITONS
Settings
Default Setting
•It's required to change it to a code of your own before programming
•In manual mode, press the "
Programming Code
123456 •6~9 digits in length, must differ from all the user codes exsits currently.
•lf you forget the master passcode, you can do initilization setting,
which restores the default programming code.
•This feature is optional and can be turned off.
•When enabled,the lock will automatically re-lock after 5/10/20/30/60
Auto Lock
Enabled seconds.
(Default 5 seconds)
•After a successful code entry or manual unlock with the key ,the lock will
automatitclly re-lock after each unlock to keep your home security.
Manually Lock
Press the " " •lf auto-lock is not enabled, you need to do the locking manually.
•The voice guiding of lock & unlock as well the beep sounds while
Mute Mode
Disable
pressing the keypad can be mute, but you can still hear the voice
guiding while do setting process.
•Privacy mode is disabled by default.
When enabled, activate Privacy mode by pressing the privacy button,
Disable
Privacy Button
for 3 seconds to put the lock in do-not-disturb mode(All Entry Codes
are disabled except the programming code ).
•Once the wrong code entry limit (10 attempts) has been met, the
Wrong Code Entry Limit
Enabled
lock wilt shutdown (flashing RED) for sixty (60) seconds.
•Prevent code exposure strangers by entering random digits.
Max in 16 digital length.
Peek-proof
Enabled
digital keypad
•The lock comes out without any default User Codes.
Must be different from the master code and other user codes.
User Code Disable
Up to 100 possible User Codes can be stored in the lock at one time.
Warranty
Lifetime Limited Mechanical and Finish Warranty and 1-Year Limited Electronics Warranty Subject to the
terms and conditions of the warranty ,We extend a lifetime limited mechanical and finish warranty and
a one-year limited electronics waranty to the original consumer user("Original User") of our brand
product against defects in material and workmanship, as long as the original User occupies the residential
premises upon which the product was originally installed.
Warning
This manutacturer advises that no lock can provide complete security by itself this lock maybe
defeated by forcible or technical means or evaded by entry elsewhere on the property, No lock
can substitute for caution, awareness of your environment, and common sense.Builder's
hardware is available in multiple performance arades to suit the application.in order to enhance
security and reduce risk, you should consult a qualified technician or other security professional.
Quick Set: The default programming code is "123456"
QUICK SET
It's required that you change it to a code of your own before programming.
1.Recommend you hit the small reset button the circuit board before assembling the unit to the bracket.
Hereinafter referred to as: PC = Programming Code
UC =User Code
Change
Programming
Code
Remark: Programming Code should be 4-9 digits in length .And you need to enter the new password again to confirm.
Add New
User Code
Remark: User Code should be 4-9 digits in length .And you need to enter the new password again to confirm.
Delete
User Code
Volume setting
Auto-lock on
or
Auto-lock off
Time delay setting: press 1 for 5s, 2 for 10s,3 for 20s,4 for 30s,5 for 60s.
Language
setting
Add One-
Time Code
Initialization
setting
Definitions
" button to lock.
Password
Random digits
New PC
PC
New PC
New PC
PC
New PC
1(single)
PC
2(all)
1(increase)
PC
2(decrease)
1(on) Set Time Delay
PC
2(off)
1 (English)
2 (Chinese)
PC
3 (Portuguese)
4 (Spanish)
New PC
PC
New PC
