IMPORTANT! READ CAREFULLY
EN
PLEASE KEEP FOR FUTURE REFERENCE!

ASSEMBLY INSTRUCTION

WARNING! The product should be assembled by adults only.
FRAME INSTALLATION AND MOUNTING REAR WHEEL
A.
1) Fold the frame and turn the screw (see fig. A-1).
2) Install the wheel in such a way that the openings for bolts and openings in wheel mounting elements lay over each other
(see fig. A-2).
3) Connect the mountings to the frame tightening the bolts with washers, using a screwdriver.
B. BICYCLE STEERING SYSTEM
Install the steering wheel and the wheel (Fig. B-1). Install the front wheel in the hole of the frame, apply a plastic cap.
Apply plastic cover and clamp on the steering pin. Install the steering wheel in upper hole the frame. Tighten mounting
ring on the steering wheel (A) and install plastic cover (B) (Fig.
SADDLE AND BASKET
C.
1) Place the screw fastening the saddle and the safety belt into the opening in the main frame and then fasten the screw with the
supplied nut (see fig. C-1a).
2) Install the plastic basket on the rear end of the frame using its in-built mounting brackets
D. HEAD-REST AND PUSH BAR.
1) Mount the head-rest to the tube behind the saddle, slipping the plastic part into the plastic socket in the tube
2) Assembly the push bar sliding one metal tube into the other
In case it is necessary, use the washers in places show on the figure.
3) Connect the assembled push bar with the head-rest.
4) Installation of steering string. Place one end of the attached wire on the mounted metal plate and fasten it using the 8 mm
flat wrench. Then insert the other end into the opening in the plate located over the mudguard of the front wheel and
fasten the nut with a wrench.
ROOF AND BAG (AVAILABLE ONLY IN DELUXE MODELS)
E.
1) Mount the roof to the bracket on the push bar behind the head-rest and then screw it with a metal screw using a
screwdriver. The installed roof shall look exactly like on the figure E1.
2) Hang the bag on the upper part of the push bar and mount the holding belts.
INSTRUCTIONS FOR USE
1) Pedal locking. The user releases locking mechanism of pedals as bicycle drive pulling towards him the oval handle located
on the right side of the front wheel axis (see fig. F1-a).
2) Hand brake. On the right there is a lever activating the brake when it is pulled up.
3) Push bar. The push bar may be disassembled very easily. It is enough to press the locking pin in the fork and take the push
bar out of the tube. Before every ride, check that all parts are functioning properly and are properly tightened. Do not use
the bike on rough, bumpy, steep roads and near water. In one time the bike can use only one child. This bike never be
towed by another vehicle or bicycle. This bike can not be used to tow other vehicles. Do not use the bike after dark or when
visibility is limited. Children should always keep both hands on the steering wheel.
B-2a).
(see fig. C-1b).
(fig. D-1).
(fig. D-2a).
WARNINGS!
1) The toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.
2) Before every use, make sure that the bicycle is properly assembled. Always keep all parts out of reach of children.
3) Do not use a bicycle when any part is damaged or are missing any parts.
4) Use only spare parts approved by the manufacturer
5) Protective equipment should be worn!
6) Do not use in traffic.
7) Max load of bike 20 kg!
8) Do not use the bike on rough, bumpy, steep roads and near water.
9) Maximum load of the basket is 3 kg.
10) Always use harness
11) Never leave your child unattended.
12) Children should always keep both hands on the steering wheel.
13) Teach your child how to use the bike, how to ride, steer, and brake.
14) In one time the bike can use only one child.
15) This bike never be towed by another vehicle or bicycle.
16) This bike can not be used to tow other vehicles.
17) Do not use the bike after dark or when visibility is limited.

CLEANING AND MAINTENANCE

1) Keep your bike clean. Dirt should be removed with a soft sponge, often flushed with water and detergent, wipe dry.
2) Check the status of all the fixing screw connections with different mechanisms of the bicycle frame, and in particular wheels.
3) Store the bicycle in dry place. In case it gets wet, clean the bicycle thoroughly using dry cloth in order to prevent corrosion.
