Bauknecht T8 S6300 3A Kurzanleitung

Quick guide
THANK YOU FOR BUYING A BAUKNECHT PRODUCT.
In order to receive a more complete assistance,
pleaseregister your product on
www.register10.eu
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
CONTROL PANEL
ON/OFF Button (hold for Reset)
1
Programme Selection Knob
2
Start/Pause Button
3
Options Buttons*
Active Care
4
Dryness Level
5
Start Delay
6
Timed Drying
7
Cycle End
8
Gentle (hold for Key lock)
9
Crease Care (hold for Mute)
10
INDICATORS
Dryness Level: Iron Dry -
Cycle Phase:
Drying -
Empty water tank -
Refer to troubleshooting section:
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is fixed correctly,
either to the dryer's water tank, or to your domestic drainage
system.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before using the dryer make sure it has been in an upright
position for at least 6 hours.
Should you wish to change the opening side of the door,
please contact our After-sales Service. (See phone number in
the warranty booklet).
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying
cycle.
- remember to clean your filters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door filter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items. For
optimal drying result, garments should be loaded one by one.
3. Close the door.
4. Press the "On/Off" button.
5. Select the most suitable programme for the type of fabric in
that load.
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
6. Select the options, if necessary.
• Using QR code in your appliance
7. Press the "Start/Pause" button to begin drying.
• Visiting our website docs.bauknecht.eu and parts-selfservice.europeanappliances.com
8. At the end of the drying cycle, a buzzer will beep. An indicator on • Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product's identifi cation plate.
the control panel signals the end of the cycle. Turn the machine
You can fi nd more information about your model online at https://eprel.ec.europa.eu/ which is the offi cial EU EPREL product database.
off by pressing the "On/Off" button, open the door and pull the
After selecting the Product Category, enter the Model Identifi er of the product. The Model Identifi er is made up of letters and numbers
clothing immediately out to prevent the formation of creases on
and can be found on the identifi cation plate, as Mod. (see image on the right).
laundry.
If the machine is not switched off manually, after about a quarter
of an hour from the end of the cycle , the appliance turns off
automatically to save energy.
2
Hanger Dry - Cupboard Dry -
Cool Down - END End of Cycle
Clean door filter - Clean bottom filter
Failure: Call after sales service
Before using the appliance carefully Before using the appliance carefully
read the Safety Instruction. read the Safety Instruction.
Lorem ipsum
D D E E M M O O
h
h h
5 6
*Note: some models may have the wording in full instead of the icons.
Extra Dry
Note that some programme/option accords with "Crease Care" system.
This means that for some hours, after the end of the drying cycle, the
drum rotates at regular intervals to prevent the formation of creases.
Note that some models perform a final cool tumble phase, for this
reason the fabrics may not feel hot.
In case of power failure, it is necessary to press the "Start/Pause" button
to restart the cycle.
Opening the door during the cycle
The tumble dryer door can be opened at any time during the cycle
to check progress and remove any garments already dry.
However, since opening the door can extend the drying time, the
recommendation is to keep the door closed throughout the cycle
process to save time and energy.
After closing the door, press the "Start/Pause" button within 15
minutes to resume the machine operation.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
10
END END
3
" "
9
3
" "
8
7
EN
1
4
3
