HIKVISION DS-PHA20-M Benutzerhandbuch

Hybrid Security Control Panel
E N G L I S H
Diagram References
Wiring and Installa on
1
1. Unlock the front cover with the supplied key, open the case of the control panel.
2. Fix the control panel case on the required place with three supplied screws.
3. Fix the SIM card module (Sold separately) with four plas c bolts.
4. Install the telephone module (Sold separately) with two plas c bolts.
5. Wire the cables.
Antenna Wiring (Wi-Fi and 3G/4G/GPRS Antenna)
1
1. Connect the pin of the pedestal to the terminal on the board or module.
2. Rotate and fix the antenna on the pedestal.
Network Wiring
2
Alarm Input/Alarm Output/RS-485/Power Supply Wiring
3
Power down the control panel before connec ng and disconnec ng accessories
and peripherals.
Alarm Input Wiring
2 1
a. NC Detector
b.
NO Detector
c. Unoccupied Zone
Tamper-proof
d.
Alarm Output Wiring
2 2
RS-485 Wiring: Wireless Receiver, keypad, etc.
3 2
2 Power Supply Wiring
4
Telephone Module Wiring
4
6. Close the case of the control panel. Lock the front cover with the supplied key.
2 Set Up
Set up via Web Client
Log Into the Web Client
Default IP Address when using mobile broswer in the AP mode:192.168.8.1. The device must be in the AP mode.
Default IP Address when connec ng the network cable with computer directly :192.0.0.64
Input the device IP address in the address bar of the web browser. Create a password to
ac vate the device and log into the web client.
Add a Camera for the Zone
The func on varies depending on the model of device.
1. Click System-Network Camera, and you can add cameras for the control panel.
2. Enter the "Device Management" page, select a zone, and select a camera to link with the
zone.
You can also link a camera with the zone via APP, refer to the Security Control Panel User
Manual for details.
Configure Video-Push
You can view the alarm video via APP and email. For detailed se ngs, refer to Security
Control Panel User Manual.
Set up via APP
1. Log into the App Store and input Hik-Connect to search and install the mobile client.
2. Log into the APP with Hik-Connect account.
3. Tap Add Device. Scan the device QR code on the rear panel (on the lable).
4. Tap Connect to a Network. Select Wireless Connec on (AP) as the connec on mode.
5. Push the AP/STA mode switch to the AP posi on, tap Confirm.
6. Tap Connect to Wi-Fi on the promt-up window. Select and connect to a stable Wi-Fi, and
click Next.
7. Create a password to ac vate the device.
8. Push the AP/STA mode switch to the STA posi on.
Note: You need to enter the Verifica on Code (on the device lable which is pasted on the rear panel) before
ac va on if you add the device by entering the device serial No.(SN).
Set up via iVMS-4200 Client So ware
1. Download and install the iVMS-4200 client so ware.
Note: Get the client so ware from the official website:www.hikvision.com.
2. Enter Device Management page, select the device in the Online Device List, click Edit
Network Se ngs, change the port as 80, and click Add to Client.
Note: You should ac vate the device for the first usage.
Specification
Hybrid Security Control Panel with Metal Case
DS-PHA20-M DS-PHA20-W2M
Model
DS-PHA64-M DS-PHA64-W4M
Wireless Detector Up to 16/56
Wireless Output expander Up to 8
Device
1 wired siren (on-board connec on)
connec on
Siren
2 wireless sirens
Keyfob 8, valid opera on interval: 3 s
4 (DS-PHA20)
on
Par
8 (DS-PHA64)
Alarm input 4 on-board zones , and 16 wired/wireless zones expadable(DS-PHA20),
or
Zone
8 on-board zones, and 56 wired/wireless zones expadable(DS-PHA64)
2 on-board outputs, and 18 wired/wireless outputs expadable (DS-PHA20),
Alarm output Alarm output or
4 on-board outputs, and 60 wired/wireless outputs expadable (DS-PHA64)
Scheduled arming/disarming Supported
SMS no fica on
Func on Supports up to 8 mobile phone numbers
(with 3G/4G/GPRS module)
2 (DS-PHA20)
Network camera accessing
N/A
4 (DS-PHA64)
iVMS-4200 (client so ware)
Applica on
Hik-Connect (mobile client)
Applica on &
ISAPI: Supports client so ware and web client
Protocol
Cloud P2P: Supports cloud P2P privacy protocol
Protocol
DC09: ARC accessible (CID/SIA)
Wired network 10M/100M Ethernet
Network Cellular Network
Supports report push- no fica on to ARC & Cloud
(with 3G/4G/GPRS module)
802.11b/g/n
Standard N/A
64/128-bit WEP,WPA/
Encryp on
N/A WPA2,WPA-PSK/WPA2-
Wi-Fi PSK,WPS
Configura on
N/A AP Mode
Indoor: ≤ 50 m
Distance N/A
Outdoor: ≤ 100 m
TAMPER Switch 1, front cover tamper-proof
1, RJ45 10M/100M Ethernet Interface
Network Interface
Telephone Interface
1, PSTN expander interface
1, extended up to 20 inputs/outputs (with RS-485 module),
Interface & and 9 wired keypads extendable (DS-PHA20)
RS-485 Terminal
Component
1, extended up to 64 inputs/outputs (with RS-485 module),
and 9 wired keypads extendable (DS-PHA64)
Siren Power Interface 1, 12V
Ba ery Interface Storage ba ery (-M model)
Installer: 1
Administrator: 1
User
User Manufactuer:1
Operator: 13 (DS-PHA20), 45 (DS-PHA64)
Tag
12
Opera on Temperature –10 °C to 55 °C (-4 °F to +122 °F)
10% to 90% (No condensing)
Others Opera on Humidity
Dimension (W × H × D) Metal Case: 351.4 mm (13.8") × 261.4 mm (10.3") × 93.3 mm (3.7")
Note: The 868 Mhz wireless siren can be enrolled to the hybrid control panel via the wireless receiver that is at the address of 9.
1
2 2
2 1
CAUTION
SUITABLE FOR MOUNTING ON
CONCRETE OR OTHER
NON-COMBUSTIBLE SURFACE ONLY
Z1 C Z2 Z3 C Z4 Z5 C Z6
N.C N.C N.C N.C N.C N.C
N.O N.O N.O N.O N.O N.O
2K2 2K2 2K2 2K2 2K2 2K2
EOL EOL EOL EOL EOL EOL
Only for device with
2 1
8 on-board zones
a 2
Security Control Panel
Security Control Panel
Peripheral Security Detector
Z
Z
NC
2.2KΩ
C
C C
c
2
Security Control Panel
2.2K Ω
Z
Z
C
C
2
Set up via APP
AP STA AP STA
2 5
AP STA
The AP mode is only Supported by device with Wi-Fi func on.
2 3
Z7 C Z8 C1 PGM1 C2 PGM2 C3 PGM3 C4 PGM4 AUX
N.C N.C
Alarm Alarm Alarm Alarm
Lamp Lamp Lamp Lamp
N.O N.O
Only for device with
8 on-board zones
2K2 2K2
EOL EOL
b
2 2
2
PGM1
C1
AUX- AUX+ D- D+
Peripheral Security Detector
NO
2.2KΩ
C
Dry Contact
d 2
TAMPER
CAUTION
COPER OR COPER WIRE CANNOT BE
EXPOSED AT THE ELECTRICAL TERMINAL
D E T E C T OR
8
2
AP STA
Wi-Fi
2 4
2 5
AUX+ BELL BELL+ D D+ DC DC+ BAT BAT+
Siren
Lead-acid
Battery
RS-485
15VDC
Power Adapter
2
2 4
2 3
AUX- AUX+ D- D+
DC- DC+
OR
......
Product Informa on
COPYRIGHT ©2019 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all informa on, including, among others, wordings, pictures, graphs are the proper es of
Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereina er referred to be
"Hikvision"). This user manual (hereina er referred to be "the Manual") cannot be reproduced,
changed, translated, or distributed, par ally or wholly, by any means, without the prior wri en
permission of Hikvision. Unless otherwise s pulated, Hikvision does not make any warran es,
guarantees or representa ons, express or implied, regarding to the Manual.
About this Manual
This Manual is applicable to the Axiom Security Control Panel Kit.
The Manual includes instruc ons for using and managing the product. Pictures, charts, images and all
other informa on hereina er are for descrip on and explana on only. The informa on contained in the
Manual is subject to change, without no ce, due to firmware updates or other reasons. Please find the
latest version in the company website (h p://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement and other Hikvision's trademarks and logos are the
proper es of Hikvision in various jurisdic ons. Other trademarks and logos men oned below are the
proper es of their respec ve owners.
This product and - if applicable - the supplied accessories too are marked with "CE" and
comply therefore with the applicable harmonized European standards listed under the RE
Direc ve 2014/53/EU, the EMC Direc ve 2014/30/EU, the LVD Direc ve 2014/35/EU, the
RoHS Direc ve 2011/65/EU
2012/19/EU (WEEE direc ve): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collec on points. For more informa on see: www.recyclethis.info
2006/66/EC (ba ery direc ve): This product contains a ba ery that cannot be disposed of
as unsorted municipal waste in the European Union. See the product documenta on for
specific ba ery informa on. The ba ery is marked with this symbol, which may include
le ering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return
the ba ery to your supplier or to a designated collec on point. For more informa on
see:www.recyclethis.info
GPRS
CN1
3G/4G
MAIN
AUX
1
2
3
......
4
Telephone Line Cut Off Indicator
Power Indicator
Telephone Module
