Operating Instructions
HDMI to USB-C® / USB-A
Video Capture Card, 4 K
Item no: 3024175
1 Operating Instructions for download
Use the link www.conrad.com/downloads
complete operating instructions (or new/current versions if available). Follow the instructions
on the web page.
2 Intended use
The product is an HDMI to USB-C® / USB-A video capture card. Some uses include video
game capture for streaming, video conferencing, live broadcasting and teaching.
The product can be used with various acquisition software (e.g., VLC Player, OBS Studio,
and AMCap).
The product is intended for indoor use only. Do not use it outdoors.
Contact with moisture must be avoided under all circumstances.
If you use the product for purposes other than those described, the product may be dam-
aged.
Improper use can result in short circuits, fires, or other hazards.
The product complies with the statutory national and European requirements.
For safety and approval purposes, you must not rebuild and/or modify the product.
Read the operating instructions carefully and store them in a safe place. Make this product
available to third parties only together with the operating instructions.
All company names and product names are trademarks of their respective owners. All rights
reserved.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and the
HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
USB4®, USB Type-C® and USB-C® are registered trademarks of USB Implementers
Forum.
3 Delivery contents
■
Product
4 Description of symbols
The symbol warns of hazards that can lead to personal injury.
5 Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on
proper handling, we assume no liability for any resulting personal injury or
damage to property. Such cases will invalidate the warranty/guarantee.
5.1 General
■
The product is not a toy. Keep it out of the reach of children and pets.
■
Do not leave packaging material lying around carelessly. This may become dangerous
playing material for children.
■
If you have questions which remain unanswered by this information product, contact our
technical support service or other technical personnel.
■
Maintenance, modifications and repairs must only be completed by a technician or an
authorised repair centre.
5.2 Handling
■
Handle the product carefully. Jolts, impacts or a fall even from a low height can damage
the product.
5.3 Operating environment
■
Do not place the product under any mechanical stress.
■
Protect the appliance from extreme temperatures, strong jolts, flammable gases, steam
and solvents.
■
Protect the product from high humidity and moisture.
■
Protect the product from direct sunlight.
5.4 Operation
■
Consult an expert when in doubt about the operation, safety or connection of the
product.
■
If it is no longer possible to operate the product safely, take it out of operation and pro-
tect it from any accidental use. DO NOT attempt to repair the product yourself. Safe op-
eration can no longer be guaranteed if the product:
– is visibly damaged,
– is no longer working properly,
2
(alternatively scan the QR code) to download the
■
Operating instructions
– has been stored for extended periods in poor ambient conditions or
– has been subjected to any serious transport-related stresses.
5.5 Connected devices
■
Also observe the safety and operating instructions of any other devices which are con-
nected to the product.
6 Connection
1. Connect the source to the HDMI Input.
à For optimal signal performance the HDMI cable should be <15 m.
2. Connect the USB Output to an available port on your computer.
à
You may need to wait a few moments for your computer to recognize the device.
3. Load your preferred acquisition software (e.g., VLC Player, OBS Studio, AMCap).
7 OBS: Open Broadcaster Software®
Open Broadcaster Software is a free and open-source cross-platform streaming and record-
ing program. OBS Studio is available for download here: www.obsproject.com.
This quick setup guide is for reference only.
1. Connect one end of the capture device to the signal source, and the other end to your
computer. See section: Connection [} 2]
2. Launch the software.
3. Under the "Sources" window, select "+" to add a new source.
4. Select "Video Capture Device".
5. Set the image size.
6. Select "Studio Mode" (double window).
7. Select "Start Recording".
Tip:
For further information relating to setup and use visit:
8 Technical data
Input ............................................... 5 V/DC, 0.4 A max.
Chassis material............................. Aluminium
USB-C® / USB-A............................ 3.0 max. 5 Gbps
Input (HDMI)................................... max. 3840 x 2160 @ 60 Hz, 4K Ultra
Output (USB).................................. max. 3840 x 2160 @ 18 Hz, 4K Ultra
Colour support................................ 8 / 10 / 12-bit deep colour
HDR support................................... yes
Supported audio format.................. L-PCM
Video colour space......................... YUV (4:2:0, 4:2:2, 4:4:4)
Still image capture.......................... JPEG
Plug and play.................................. yes
Supported OS................................. Windows® 7, 8, 8.1, 10 (or above),
Operating temperature .................. -10 to +50 °C
Operating humidity ........................ 10 - 90 % RH (non-condensing)
Storage temperature ...................... -20 to +70 °C
Storage humidity ............................ 10 - 90 % RH (non-condensing)
Dimensions (W x H x D) (approx.) . 51 x 23 x 9.6 mm
Weight (approx.) ............................ 350 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in
electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
This publication reflects the technical status at the time of printing.
Copyright by Conrad Electronic SE.
*3024175_V2_0224_dh_mh_en 9007200469648907-2 I2/O2 en
.
www.obsproject.com/wiki
Linux 16.4 (or above),
MacOS 10.10 (or above)
.
