ENGINEERING DRAWING
F
(overlapping part)
G
I
H
D

Accessories:

85161, 85161YEL, 85161GREY
DEFENDER
OFFICE C (90° curve )
®
E
H
J
A 125 mm / 5.0"
B 90 mm / 3.5"
C 50 mm / 2.0"
D 125 mm / 4.9"
E 865 mm / 34.1"
85168, 85168YEL, 85168GREY
DEFENDER
OFFICE ER (End ramp)
®
OFFICE
B
A
D
C
F 210 mm / 8.3"
G 50 mm / 2.0"
H 10 mm / 0.4"
I 12 mm / 0.5"
J 20 mm / 0.8"
7
