A green LED will flash on to identify the active
channel
.• Use the RESET button on the remote control
to set the product into initial condition.
This action is a circular function.
When you have choosed a channel, the dedi-
cated LED flashes on. E.g. Choose channel 1 –
LED CH1 flashes on.

5.4 4K2K and 3D Application:

1. Ensure all devices (HDTVs, Receivers, cables,
Blu-Ray Players, etc.) support the same 3D
TM
formats.
2. If a device supports no 3D, on all devices 2D
will be displayed.
Frame Side-by-Side
packing (Half)
1920x1080p 1920x1080i
@23.98/24Hz @59.94/60Hz
1280x720p 1920x1080i
@59.94/60Hz @50Hz
1280x720p
@50Hz
5.5

Operation Mode Overview:

Adjustment Output format
VIDEO/AUDIO:
highest format, suppor-
ted by both outputs
VIDEO:
highest possible output
format
AUDIO:
highest format, suppor-
ted by both outputs
VIDEO:
highest format, suppor-
ted by both outputs
AUDIO:
highest possible output
format
VIDEO/AUDIO:
highest possible output
format
Clicktronic®
Top-and- 4K2K
Bottom
1920x1080p 4096x2160
@23.98/24Hz @23.98Hz
1280x720p 3840x2160
@59.94/60Hz @23.98/24Hz
1280x720p
@50Hz
Example
Output device
OUT A
1080p/Stereo
1080i/Stereo
1080p/Stereo
1080i/Stereo
1080p/Stereo
1080i/Stereo
1080p/Stereo
1080i/Stereo
Resetting:
Output device REPRODUC-
OUT B TION OUT A/B
1080i/Stereo 1080i/Stereo
720p/Stereo
1080i/ 1080p/Stereo
Dolby5.1, Stereo
720p/
Dolby5.1, Stereo
1080i/ 1080i/Dolby5.1
Dolby5.1, Stereo
720p/
Dolby5.1, Stereo
1080i/ 1080p/Dolby5.1
Dolby5.1, Stereo
720p/
Dolby5.1, Stereo
