safety instruction

!
Please follow the instructions for use as this is the only way to ensure proper operation
of the "Tronix-audio" module. Water is fatal to most electronic devices unless they are
waterproofed. "Tronix-audio" modules are NOT intended for use Intended for use in a
humid environment. Under no circumstances must liquids or other conductive
substances penetrate the module. In this case, the module must be unplugged, dried
immediately and inspected and cleaned by a qualified technician. Do not expose the
module to temperatures above +50°C or below -15°C. All modules may only be
operated with a Eurorack-compatible internal power supply (doepfer etc.), with a
maximum of +/-12 volts! ATTENTION: DANGER TO LIFE IF NOT PERMITTED USE
OF HIGHER VOLTAGES OVER 50 VOLT !!!
This module is a musical instrument and should be treated as such. Install carefully and
don't drop it. Any existing warranty does not apply to modules with visible damage. Any
module shipped to us for return, exchange and/or warranty repair must be in its original
packaging. All other deliveries will be refused and returned to you. Make sure you keep
the original packaging and technical documentation.
If contractually agreed, items for exchange and/or warranty repairs must be sent to:
M.Jenzsch
Karl-Marx-Platz 6
06242 Braunsbedra OT Roßbach
Deutschland.
Designed and made in Germany by Mario Jenzsch @ Tronix-audio.
Technical data can be changed without notice!
If you have any questions,
please feel free to contact us by email: tronix-audio@web.de.
THANK YOU FOR SHOPPING !
The modules from "Tronix-audio" are developed and manufactured in small series in
Germany and undergo strict quality control. Many components are checked for tolerances
before assembly and selected if necessary. The modules always have a mechanical and
electronic reverse polarity protection of the power connection (box connector and rectifier
diodes), and the inputs and outputs are protected against unwanted overvoltage (in the
appropriate Eurorack range)
NOT AGAINST HIGH VOLTAGE! ATTENTION DANGER TO LIFE WHEN USING
HIGHER VOLTAGES OVER 50 VOLTS !!!
APOLLO
The module :
Apollo is a classic CV and AUDIO processor for the Eurorack. It is primarily intended to
deliver, mix, bend and shift tension. In addition, CV's and AUDIO are also amplified,
attenuated, added, subtracted, multiplied or tilted.
Apollo is not a surgical digital precision tool but a fully analog Eurorack module with its
own character and the usual tolerances. The LED displays can deviate by up to +/- 0.5V at
voltages outside of +/-6V (but trimmers for adjustment are available).
Supported Voltage processes : Addition, subtraction, multiplication, offset, inversion,
"tilt"
Supported AUDIO processes : Mixing, gain levelling, offset distortion, splitting,
amplification

TECHNICAL SPECIFICATIONS:

power consumption................................... +12Volt 42mA, -12Volt 38mA
module width ............................................24 HP / 12,1cm
module depth ........................................... 34mm
Reverse Power Protection / Eurorack synth compatible
