STORAGE
Wine Storage
WINE RACKS
The full-extension racks provide easy access to 750 ml,
half-bottles and magnums. When storing magnums, the
rack above must be removed.
To remove a wine rack, pull out to full extension, tilt up, then
lift up and out. Refer to the illustration below. The top two
racks in the upper compartment and top rack (top two for
model ICBIW-30R) in the lower compartment cannot be
placed in any other position. These racks can be identified
by the small square cut-out located in the right rear corner.
Refer to the illustration below.
The natural cherrywood facing on wine racks can be stained
or replaced with wood to compliment cabinetry. For more
information, refer to the Sub-Zero design guide or contact
your authorized Sub-Zero dealer..
CAUTION
Remove all bottles from the wine rack before removal.
CUT-OUT
Wine rack removal. Rack position indicator.
DISPLAY RACK
The adjustable display rack is designed for wine to stay in
contact with the cork at any position. Refer to the illustration
below.
To remove the display rack, pull out to full extension, tilt up,
then lift up and out.
Display rack.
Storage Drawers (ICBIW-30R)
DRAWER DIVIDERS
To remove or adjust a short divider, flex the long divider
slightly, then pull upward. Refer to the illustration below.
To remove a long divider, the short dividers must be
removed. Pull divider up until it stops, rotate counterclock-
wise, then pull upward. To reinstall, align grooves with
drawer tabs, rotate clockwise, then slide down.
Drawer dividers.
DRAWER REMOVAL
To remove, pull open until drawer stops. Raise the drawer
front and pull out drawer. To reinstall, raise the front of
drawer and place onto the slides. Align the back of the
drawer with hooks on the slide, then align the white pegs
at the front of the slide with holes at the front of the drawer.
Refer to the illustration below.
Drawer removal.
