User Manual
Introduction
Thank you for purchasing the LINDY USB 2.0 Cat.5 Extender. This product has been designed to
provide trouble free, reliable operation. It benefits from both a LINDY 2 year warranty and free lifetime
technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
This USB 2.0 Cat.5 Extender is composed of a Transmitter and Receiver. It enables a USB 2.0 host
device to send data up to 60 metres. The receiver unit has an integrated 4 port hub for connection of
multiple USB peripherals.
Package Contents
•
Transmitter Unit with fixed 12cm USB A male cable
•
Receiver Unit
•
5V DC 4A Multi-Country Power Supply (with
•
This Manual
Features
•
Supports USB 2.0 High Speed devices up to 480Mbps, backwards compatible with USB 1.1
•
Plug and play, no driver installation required
•
Extends USB 2.0 high-speed and USB 1.1 devices up to 60m over Cat 5e (or better) cable
•
Integrated four port hub
•
Supports all major operating systems with USB support
Specification
•
Transmitter with 1x USB 2.0 A male port and 1x RJ45 female port
•
Receiver with 1x RJ45 female port, 4x USB 2.0 A female ports, DC power socket (3.5/1.35mm)
•
LEDs: white for power, green for link / RJ45 connection
•
Dimensions: 5.2 x 6 x 2cm each
•
Operating Temperature: 0 – 50°C
•
Storage Temperature: -20 – 70°C
Installation
1.
Connect the Transmitter to a USB port on the host computer.
2.
Place the Receiver near the USB device(s) in the desired remote location.
3.
Connect the supplied 5VDC 4A power adapter to the Receiver.
4.
Connect the Transmitter and Receiver by using a Cat.5 (or better) cable (not included).
UK, Euro, US, AUS plug)
English
for Receiver
