Quick Installation Guide *
Clesana Power-Management
12
Auto
02
Off
Man
05
+EBL-
30 A
09 11
Constant plus**
*
This Quick Installation Guide does not replace the complete installation and operating instructions. Please be sure to read
and follow them to ensure safe and correct installation.
* *
Constant plus cable: The existing cable for flushing the cassette toilet is not automatically a constant plus cable! A constant
plus cable is absolutely necessary. Otherwise, the battery will not be charged when installed as a buffer battery. When instal-
led as a relay, this is not activated and does not release the current flow from the supply battery to the Clesana C1. If the
existing cable is not a constant plus cable, it can be reconnected in the EBL to a slot that carries constant voltage. Alternati-
vely, a new control cable must be drawn from a constant voltage source.
+Batt-
25A
+ Toilet -
06
07
08
-
+ +
03
04
Off
On
1 1
2 2
D1 D2
EN
01
Clesana Power-Management incl. cables:
Steps for installation in combination with a
buffer battery
02
03 Dip switch D1
Position for installation via buffer battery: D1 ON
04
Dip switch D2
If buffer battery type
= supply battery:
D2 ON
e.g. AGM & AGM or
LiFePo4 & LiFePo4
05
06
07
08
09
10
Connect the
Attention: the
11
12
13
14
Switch off the water pump or make sure that it is switched off. Can the Clesana C1 be started?
Yes, the Clesana C1 can be started
Switch off the main switch of your vehicle
Clesana Power-Management without cables:
Steps for installation as a relay on the
Set the switch on the Power-Management to the OFF position
Position for installation via suppl battery: D1 OFF
04
Dip switch D2
If LiFePo4 buffer
battery and AGM
When installed as a relay on the supply
supply battery:
battery (no buffer battery):
D2 OFF
Attention: AGM buffer
battery not permitted for
LiFePo4 supply battery!
red battery cable
to the Batt. + connection
Connect the
Connect the the black battery to the Batt. - connection
red battery cable
to the Toilet + connection
Connect the
Connect the the black battery to the Toilet - connection
Note: do not connect the black toilet cable (earth) to the chassis!
Pull out the
green EBL
block
red control cable
EBL +
and the black control cable to
to
red cable
must be a constant plus cable** (constant voltage)!
Re-insert the
green EBL
block
Set the switch on the Power-Management to the Auto position
Switch on the main switch of your vehicle
Check the electrical installation as follows:
No: the control cable does not carry any voltage
(no constant plus), see 10
Note: check steps 3 - 11 for correct
supply battery
03 Dip switch D1
04 Dip switch D2
D2 ON
EBL
-.
implementation
