MRA ZERO DS/R HKSZ Montageanleitung Seite 3

GB
Read this manual carefully and check the parts list for completeness before you begin. We recommend
Number
1 MRA screen
1 Bracket set consisting of:
4 Round head screws, M5 x 16 mm
4 Allen screws, M5 x 16 mm
8 Nuts, black, M5
2 Rod end caps
2 Ball bar, 60 degrees, 170 mm
2 Ball socket
2 Cover
2 Clamp, 20x15x30
2 Allen screws, M8 x 55mm
2 Steel spacers 10mm
How to mount the bracket onto the screen:
1. Insert the nuts (7) in the lateral hex pockets of the ball clamps (2) and screw in the Allen screws (6)
(but do not tighten them yet) (P1).
2. Slide the rod clamp onto the rod.
3. Install the ball bar (1) with the ball clamp (2) and the cover (4) at the screen. Use the flat screws (5)
and the nuts (7) and tighten them (P1).
How to mount the screen on your motorbike:
4. Place your motorbike on a level surface.
5. Screw out the rear screws from the handlebar clamp (P2).
6. Position the screen with the bracket onto your bike and install the rod clamps at the handlebar
clamp (P2) using the M 8 x 55 screws and 10 mm spacers. Position the screen with the brackets on
the bike and fasten the rod clamps at the triple clamp (P2).
7. Align the screen and rods and tighten all screws.
8.
The screws of the handlebar clamp are tightened using a torque of 27 Nm.
After installation, check that all of the screws are tight; tighten them up if necessary. Repeat this at
regular intervals. Clean the screen with water, neutral soap and a sponge. Do not use solvents, alcohol or
MRA-Klement GmbH Siemensstr. 6 D-79331 Teningen Tel.: +49 7663 93890 Email: info@mra.de
Thank you for buying a MRA Windshield.
that you have your screen fitted by an authorised workshop.
Article
spirits to clean the screen as they will damage it.
MO UN T IN G IN STR UC T ION S
Zero DS/R
Article No..
--- Torx T25 / T30 / T45
Allen keys 3, 4 and 6mm
10554
10560
10557
10550
10706
10543
10542
10696
10791
10776
3
Required tools
