RHEINTACHO RT STROBE pocketLED LASER Schnellstartanleitung Seite 3

Brief description of set-up steps
Please follow th e steps below when setting up the device:
1. Place 3 AA size batteries or NiMH rechargeable batteries
into the device.
2. Direct the device at a moving object and switch on. Press
the button "ON / OFF" for at least 1 second.
The device will start to flash straightaway. For this
reason, do not direct it at people or animals.
• The device will flash at the frequency that was set most
recently. The display shows the selected flash frequency in
the unit that was set most recently (1/min, Hz or FPM).
▪ If the flash frequency coincides with the frequency of the
motion, a static image appears.
▪ If necessary, reset to factory setting by pressing and holding
the buttons Menu "M" and "MINUS" simultaneously.
Note
Static images are produced when the flash frequency is
identical to, or a multiple or fraction of the frequency of the
motion.
Button assignment
Description
Button
- Switch on the device by pressing the
ON / OFF
button for at least 1 second.
Menu - Press this button to switch between the
different settings and operation modes
in the sequence of the display indicator.
- Press this button to activate the laser.
Laser
- This button can also be used to confirm
selected settings.
MINUS - Decreases the currently selected value.
- Switch between the various settings.
- Increases the currently selected value.
PLUS
- Switch between the various settings.
DIV - Halves the currently selected value.
MUL - Doubles the currently selected value.
Note
The symbol of a parameter that differs from the factory
settings will flash during operation.
Printed CE declaration of conformity is available on request.
Subject to technical changes without prior notification.
Although the content of these instructions was compiled with
the greatestcare, we cannot accept liability for any errors.
Standard selection
Note
Not all of the settings shown are available in standard
selection.
Display Adjustable
parameters
Off -
Display
resp. setting
the frequency
Mode TACHO /
STROBO
Brightness BRIGHT deg.:
0,025° ... 6,000°
The complete operating instructions with examples can be
found on our homepage.
Quick Start Guide RT STROBE pocketLED LASER
Description
Device is switched off.
Display resp. setting the
frequency frequency in 1/m,
Hz or FPM.
Change the frequency by
pressing the buttons
"PLUS", "MINUS", "DIV"
and/or "MUL".
Selection of the mode:
TACHO or STROBO
Setting the brightness
(in degrees).
