LUCCI SMITH 269391 Installationsanleitung

Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this luminaire. Please keep instructions for future reference.
Warranty
• This portable luminaire is covered by a 5-year warranty valid for in-store replacement or refund only.
• The warranty period starts from the date of purchase. Please retain the proof of purchase.
• Warranty will be void if there is any damage due to improper usage or modification to the portable luminaire.
• Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the
warranty.
Installation Requirements
• Select a suitable location for the portable luminaire: - Ensure it is on a flat and stable surface.
This portable luminaire is suitable for indoor use only.
-
Do not place flammable material near or over the portable luminaire.
-
Ensure the portable luminaire is not installed in direct line of an air vent/system.
-
If the portable luminaire is placed in an area prone to moisture, ensure that the area is well ventilated, and an
-
appropriately rated exhaust fan is used if required. Damage or corrosion caused by moisture is not a product fault,
and as such is not covered under warranty.
• Only use the supplied plug in LED driver with this luminaire.
• Take care not to pull any electrical wires during unpacking as this may damage the connection.
• Lay out all the components on a smooth surface and make sure no components are missing before assembling.
If parts are missing, return the complete product to the place of purchase for inspection or replacement.
• Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
• Do not plug into the mains power socket outlet before or during assembly. Only do so after the portable luminaire is
fully assembled and is ready to use for the first time.
Installation Directions
1. Remove all packaging material from the portable luminaire.
2. Select a suitable location for your portable lamp. See the requirements above.
3. Plug the LED driver connector (B) into the luminaire socket (C).
4. Plug the LED driver (A) into the mains socket outlet and ensure it is fully plugged in.
5. Turn on the mains power socket outlet.
6. Press the switch button (D) to turn the luminaire on and off. Press and hold the switch button (D) to adjust the
brightness level of the luminaire.
Operation of the USB charger (E):
You can charge your electronic device via the USB output (E) on the base of the luminaire. The
USB output (E) is rated DC 5V 2 A.
(Refer to the instruction manual of your electronic device for the required charging current)
NOTE:
If the charge current of your device is over the limit of the rated current, the charger will be self-
protected.
In this case, your device will not charge unless you reconnect according to the rated output.
1 P a g e
|
SMITH LED TABLE LAMP
SKU# 269391, 269392, 269393
Rated Voltage 12V 2A
v 1 . 0 0 1 / 2 0 2 2
