In the event of fire, be warned in plenty of time by FlammEx smoke
GB
detectors so that you can make your escape.
If the emergency exits are blocked and the fire service has not yet arrived, a
FlammEx rescue ladder provides an escape route when the only way out is
through a window or over a balcony.
Tested to current standards (BGI 638 - previously ZH 1/368), the universal
rescue ladder is made of fire-proof, high-quality aluminium and is fitted with
an integrated (steel) wall hook for quick and easy use to ensure a fast and
safe alternative emergency exit.
Available types:
• Length 5 m (for approx. 2 floors)
• Length 8 m (for approx. 3 floors)
For an escape route via a balcony,
balustrades or sloping roof.
For use in any position where the
rescue ladder cannot be directly
attached to a wall.
Installation:
Locate a stable attachment point on which to hang the rescue ladder for a
safe descent. Balconies, balustrades, sloping roofs or sturdy heating pipes
generally provide a firm hold. Where there is no other suitable means of
mounting, the wall-mounted holder (available as an accessory) will need to
be mounted on the brickwork.
Hook the steel wall hook over a
stable attachment point.
Unfold each rung individually or in
a bundle.
Release the fixing clip by gently
pressing the rungs together.
Climb down keeping your arms and
legs extended.
Rescue ladder
FPL # 004115
FPL # 004306
Behaviour:
• Keep calm
• Make sure that the attachment point is stable before climbing onto the
ladder.
• Climb down the ladder keeping your arms and legs as extended as
possible
• Hold tightly onto the rungs and climb down the ladder, placing the
centre of your foot onto each rung. Climb down as follows:
Feet and hands moving in unison:
right foot + right hand, left foot + left hand
or alternating feet and hands:
right foot + left hand, left foot + right hand
• People on the ground can hold onto the ladder to keep it steady and
make it is easier to climb down.
• Several people should climb down the ladder one after the other.
Folding together:
Lay out the rescue ladder lengthwise on the fl oor. While holding the fi rst
rung, turn the second rung 180° to the right.
Then turn the next rung 180° in the opposite direction. Turn the next rung
180° in the opposite direction. Continue in this way up to the last rung.
Then gently press the rungs together and fi x the rescue ladder in place using
the fi xing clip.
Keep the spacing between each
rung taught.
Side view of correct rope position.
Note:
• Protect the rope ladder from damage
• Do not use the rope ladder if damaged
• Before using the rope ladder, check that it is suitable for use and in
good condition
• Follow the user instructions
Gutkes GmbH
Rehkamp 13 Fax: +49(0) 511 / 958 58 05
30853 Langenhagen www.gev.de
Germany service@gev.de
Turn 180° to the right
then 180° to the left, etc.
Attach the fixing clip by gently
pressing the rungs together.
