System design

Input driving and switching:
manual control
LH01
XpressNet: 4 wires (L,M,A,B)
feedback
2 wires (R,S)
Feedback
modul
This graphic presentation shows the simple system design of the
Digital plus by Lenz system.
manual control
LH100
command station
with
amplifier
LZV100
Switch
decoder
First Steps SET100
Computer
Interface
LAN/USB
Transformer (U,V)
Programming track (P,Q)
To the track (J,K)
Locomotive
decoder
