Overview of the controls and connectors

Front panel

1. Adjust the audio volume
2. Store and select preset stations
3. Enter options menu
4. Switch between DAB/FM/CD/Auxiliary
source
5. 3.5mm stereo headphone socket
6. Enter station list (DAB) or tuning (FM)
Top
PowerPort
Underneath
2
PowerPort for compatible USB accessories
play/pause & stop
skip forward/backwards. Hold for fast forward or rewind
Snooze button
USB input socket
(mini B type) for
upgrades
Power input socket for
supplied 9V DC mains
adapter
7. Enter alarm setup
8. Set sleep timer
9. Switch between Standby and On
10. 3.5mm auxiliary socket
11. Navigation dial. Rotate to navigate
menus, push to confirm selections
9V DC
