Palmer PMT08 Technische Daten

MANUFACTURER'S WARRANTY & LIMITATION OF LIABILITY
The technical data and functional product features may change without notice. We can nevertheless not
be held responsible or liable for the accuracy and completeness of the information provided.
You can find our current warranty conditions and limitation of liability at: http://www.adamhall.com/media/
shop/downloads/documents/manufacturersdeclarations.pdf
PROPER DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste separation)
This symbol on the product, or the documents accompanying the product, indicates that this appliance
may not be treated as household waste. This is to avoid environmental damage or personal injury due
to uncontrolled waste disposal. Please dispose of this product separately from other waste and have it
recycled to promote sustainable economic activity.
SCHEME:
2
1
CONNECTIONS:
Footprint 30 x 30 cm, Height 20 mm (excluding pins)
4
INTPUT
3
Galvanic isolation of line levels
JACK
INPUT
max. 6 dB
10 k Ω
Unbalanced to balanced
JACK
INPUT
© Palmer Audio Tools, Adam Hall GmbH, D-61267 Neu-Anspach, Daimlerstr. 9, Germany TEL: ++49 (0)6081 94190
FAX: ++49 (0)6081 43280 WEB: www.adamhall.com, www.palmer-germany.com EMAIL: info@palmer-germany.com
PMT08 – BALANCING TRANSFORMER 1:1
Description
Home recording level (-10 dB) line isolating transformer balances CD players, tape decks etc. Electrostatic
and mu-metal shielding, PCB mount. PCB for 4 x PMT-08 available (PCB08).
CAUTION: Soldering time on the contact pins should be no more than 5 seconds. No warranty for da-
maged or over-soldered pins!
TECHNICAL SPECIFICATIONS
Ratio:
Source impedance:
Load impedance:
Max. level:
Frequency response:
Coil body:
application:
Weight:
(VIEW ON THE PINS)
2
4
OUTPUT
1 3
PMT08
2
4
1 3
PMT08
HOUSING
2
PHASE
4
PHASE
1 3
PMT08
1:1
< 10 k Ohm(s)
> 10 k Ohm(s)
+ 6 dB
30 - 20000 Hz
EE25
line isolator
0.08 kg
GRID:
JACK
OUTPUT
1
3
2
(5 MM)
