En | Quick Start Guide - Unu Move Basics Schnellstartanleitung

EN | Quick Start Guide

Unbox your scooter
On/off, lock, seatbox
Mount your mirrors
L R
Display & battery
It's best to have a second person
help unbox the scooter.
1. Remove the top lid of the box.
2. Remove the four side walls by
sliding them upwards.
1. Lock/turn off button
2. Unlock/turn on button
3. Seat box button
Your scooter should be in park
mode and its handlebar unlocked
1. Place both mirrors on a flat
surface so that they form a V
shape.
2. Pick the left mirror and turn the
bottom nut all the way up until
you feel resistance.
3. Screw the bolt clockwise into
the left side of the handlebar. It
is normal that the bolt doesn't
go all the way in. Do not use
force!
Speedometer
Odometer
Battery state of charge
Are you Happy?
Share your experience on social
and tag @unu
Turn On:
Press the Unlock/turn on button.
Fold the kickstand up to enter
drive mode.
Turn Off:
Press the Lock/turn off button.
Lock:
Turn the handlebar all the way to
the left and long press the lock/
turn off button (1) until you hear
the locking sound on the scooter
(approx. 5 sec.).
17
17
Having troubles?
we are here to help, visit
unumotors.com/en-de/help-center/
3. Lift the back wheel by the rear
handle and move it off the
platform.
4. Lift the front wheel off the
package by the handlebar.
5. Unfold the kickstand to stabi-
lize the scooter.
Seat box:
Press the seat box button twice.
This works also when the scooter
is off.
You may also open the seat box
with the button on the left side of
the handlebar when the scooter
is on.
Reminder: If no main battery is
connected, the display of the
scooter will be off. Don't forget
to turn off your scooter before
removing the battery.
4. Turn the mirror into a position,
so that you can see what is be-
hind you (this can be adjusted
later).
5. Tighten the nut with a wrench
(17mm) until the mirror is fixed
in one place.
6. You can loosen the nut at the
top of the mirror arm to adjust
the mirror's vertical orientation.
Make sure to tighten the nut
again.
7. For fine tuning, press gently on
the mirror glass to change its
orientation.
8. Repeat with the right mirror.
Charge your battery
Turn off the scooter, open the seat
box via the key fob and unplug the
battery.
Plug the battery to the charger by
pressing the plug on the connec-
tor.
The battery is fully charged when
the led on the charger turns green.
To use your battery, turn off your
scooter and plug in the battery
cable.
unu Scooter Move basics
Version 1.0
2
