AXIS Long Range PoE Extender Kit

LED Indicators

LED
1
1, 2
1, 2, 3
1, 2, 3, 4
1, 2, 3, 4, 5
1
1, 2
1, 2, 3
1, 2, 3, 4
1, 2, 3, 4, 5
Color/be-
haviour
Green. Steady
during normal
operation.
Green. Flashes
during normal
operation.
14
Indication
5 W PoE enabled to device.
10 W PoE enabled to device.
15 W PoE enabled to device.
20 W PoE enabled to device.
25 W PoE enabled to device.
5 W PoE available but not enabled
to device.
10 W PoE available but not enabled
to device.
15 W PoE available but not enabled
to device.
20 W PoE available but not enabled
to device.
25 W PoE available but not enabled
to device.
