Installing Accessories

Installing Flash Tube
Connecting to Battery Pack
Connecting Flash to Camera
1. Loosen locking ring on the Hot Shoe Mount.
2. Slip the Hot Shoe Mount of the flash unit into the camera's Hot Shoe.
3. Secure flash unit by tightening the locking ring.
This flash unit is not powered by itself, but draws power from the
GENESIS PowerPort Duo 1000 external battery pack, CF0200, CF201,
CF0202 (sold separately)
1. Remove the Reflector or other accessories
from the Flash Head.
2. Match the red dot on the base of the Flash
Tube with the red dot in the Tube Socket
(4). Push the Flash Tube in until it is
securely seated into the socket.
1. Before connecting, make sure that the
Battery Pack is turned off.
2. Plug one end of Power Cable into Power
Socket (6) of the Flash Unit, and insert the
other end into the output socket of the
Battery Pack.
3. Turn on the Battery Pack.
5
