3PAGEN 687970 Gebrauchsanleitung

Product name:
Item No: 687970
GB INSTRUCTION MANUAL
Please read and retain these instructions for future reference
Total length
Empty vehicle
mass
Glide offset
Wheel location
Static stability
Packing List
Wheelchair, manual
Main structure
Manual wheelchairs are mainly composed of a frame, cushions, armrests, pedals, front wheels, rear wheels,
and brakes.
Scope of application
Manual wheelchair is used as a means of transportation for the disabled, the sick and the elderly and infirm
who have mobility difficulties.
Manuel Wheel Chair
v001: 30/03/2025
Total width
≥1200mm
≤25kg Slope performance
Maximum radius of
≤350mm
gyration
All wheels except the lifting wheel must land stably
Longitudinal forward tilt ≥10°, longitudinal backward tilt ≥10°, roll ≥15°
Dimensions
Open size: 97 x 56.5 x42cm/folded: 86 x 31 x 31cm
Seat width: 45cm
• Super lightweight, weighs just 8.9kg which is less than a bag
of compost!
• Comes with a fabric suitcase on wheels for easy
transportation (suitcase has adjustable handle and folds
away small)
• Supplied with 2 in 1 seat pad, use without red seat pad in
warmer weather and the mesh is breathable to keep you
cool when sitting for long periods
Fold away fully
•
Pocket at the back of the wheelchair
•
Height adjustable foot rest
•
Brakes on both back wheels
•
• Arms can lift up and click back into position
Includes seat belt
•
≤700mm
≥8°
≤1400mm
Maximum load ≤100kg
Minimum
reversing width ≤1500mm
Minimum radius
≤850mm
of gyration
