2. TECHNICAL FEATURES
VOLTAGE POWER INPUT POWER OUTPUT OVEN CAPACITY EXTERNAL DIMENSIONS
230V ~ 50Hz 1550W
3. INSTALLATION

3.1. SETTING UP YOUR OVEN

Remove the oven and all materials from the carton and oven cavity.
Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect the
magnetron.
Your oven comes with the following accessories:
1 Instruction Manual
PARTS NAME
A) Control panel
B) Observation window
C) Door assembly
D) Safety interlock system
E) Ceramic board
NOTE:
Don't press the ceramic board forcibly.
Take and put the gently during the operation in order to avoid damage To the ceramic board
After using, don't touch the ceramic board by hand in order to avoid h i g h temperature scald
3.2. INSTALLATION
1) Select a level surface that provide enough open space for the intake and/or outlet vents.
The rear surface of appliance shall be placed against a wall.
A minimum clearance of 30cm is required between the oven and any adjacent walls.
Leave a minimum clearance of 30cm above the oven.
Do not remove the legs from the bottom of the oven.
Blocking the intake and/or outlet openings can damage the oven.
Place the oven as far away from radios and TV as possible. Operation of microwave oven may
cause interference to your radio or TV reception.
2) Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same
as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If
installed near or over a heat source, the oven could be damaged and the warranty would be
void.
USER MANUAL
1000W 25L
C
D
GB 5
511x421x285mm
B
E
NET WEIGHT
13,5 Kg
A
