IKA RCT
IKAMAG Magnetic Stirrer
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
Limited Availability
New From Surplus Stock
Open Web Page
https://www.artisantg.com/62198-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r
Inhaltsverzeichnis
loading

Inhaltszusammenfassung für IKA-WERKE HCT basic safety control

  • Seite 1 IKA RCT IKAMAG Magnetic Stirrer Limited Availability New From Surplus Stock Open Web Page https://www.artisantg.com/62198-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . •...
  • Seite 2 -WERKE ® 50 055 00 RCT basic safety control HCT basic safety control ® ® Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 4 RCT basic HCT basic safety control safety control G H I G H I Fig. 1 Fig. 2 Pos Bezeichnung Item Designation Pos. Désignation Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 5: Sicherheitshinweise

    Inhaltsverzeichnis Sicherheitshinweise Zu Ihrem Schutz • Lesen Sie die Betriebsanleitung vor Inbetriebnahme voll- ständig und beachten Sie die Sicherheitshinweise. • • • • • Achtung - Magnetismus! • Verbrennungsgefahr! • • CE-Konformitätserklärung • • • • • Achtung! Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 6 • • Chemische Reaktionen von PTFE treten ein im Kontakt mit geschmolzenen oder gelösten Alkali- und Erd- alkalimetallen, sowie mit feinteiligen Pulvern von Metallen aus- der 2. und 3. Gruppe des Periodensystems bei Temperaturen über 300-400 °C. Nur elementares Fluor, Chlortrifluorid und Alkalimetalle greifen es an,Halogenkohlenwasserstoffe wirken •...
  • Seite 7: Auspacken

    Auspacken Bestimmungsgemäßer Gebrauch Auspacken Verwendung Verwendungsgebiet Lieferumfang RCT basic safety control HCT basic safety control Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 8: Bedienung

    Bedienung RCT basic safety control HCT basic safety control Inbetrieb- nahme ¢ ¢ Rühren ¢ ¢ Heizen ¢ ¢ Anschluss externer Thermometer ¢ (direkte Temperaturregel- ung im Medium) ¢ ¢ Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 9: Betriebsmodi Einstellen

    ¢ Achtung: Die eingestellte Sicherheitstemperaturgrenze muss immer mindestens 25 °C unterhalb des Brennpunktes des zu bearbeitenden Mediums liegen! HCT basic safety control Funktionstest Sicherheitsskreisabschaltung Werkseinstellung: Modus A Err 25 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 10: Temperatur- Regelmodus Einstellen

    Temperatur- Regelmodus einstellen Montage Stativstab Werkseinstellung: PI-Modus Fig. 6 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 11: Instandhaltung

    Zubehör Instandhaltung www.ika.net Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 12: Fehlercodes

    Fehlercodes Fehlercode Ursache Folge Korrektur Achtung! Nur für autorisiertes Servicepersonal: Steckverbindung des Motors im Geräteinneren überprüfen (Temperatur des Regelfühlers) (Temperatur des Sicherheitsfühlers) Achtung! Nur für autorisiertes Servicepersonal: Steckverbindung des Heizelements im Geräteinneren überprüfen Achtung! Nur für autorisiertes Servicepersonal: Regeltemperatur Steckverbindung der Temperaturfühler im Geräteinneren überprüfen Achtung! Nur für autorisiertes Servicepersonal: Sicherheitstemperatur Steckverbindung der Temperaturfühler im Geräteinneren überprüfen...
  • Seite 13: Technische Daten

    Technische Daten RCT basic safety control HCT basic safety control Gerät Motor Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 14: Gewährleistung

    RCT basic safety control HCT basic safety control Aufstellplatte Heizen Einstellbarer Sicherheitskreis * Die angegebene Regelgenauigkeit wurde für folgende Werte ermittelt: 500 ml Wasser im 600 ml-Becherglas , Rührstab 40, 600 rpm, 50 °C Gewährleistung Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 15: Safety Instructions

    Contents Safety instructions For your protection • Read the operating instructions in full before starting up and follow the safety instructions. • • • • • Caution - Magnetism! • Risk of burns! • CE-Declaration of conformity • • • •...
  • Seite 16 • Chemical reactions of PTFE occur in contact with mol- • ten or solute alkali metals and alkaline earth metals, as well as with fine powders of metals in groups 2 and 3 of the periodic system at temperatures above 300 °C - 400 °C. Only elementa- ry fluorine, chlorotrifluoride and alkali metals attack it;...
  • Seite 17: Unpacking

    Unpacking Correct use Unpacking Range of use Contents of package RCT basic safety control HCT basic safety control Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 18 Operation RCT basic safety control HCT basic safety control Commissioning ¢ ¢ Stirring ¢ ¢ Heating ¢ ¢ Connecting external thermometers (direct temper- ¢ ature control in the media) ¢ ¢ Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 19: Setting Operating Mode

    Warning: The safe temperature limit must always be set at least 25 °C lower than the flash point of the media to be pro- cessed. HCT basic safety control Functional check of inactivating the safety circuit Factory setting: Mode A Err 25 Artisan Technology Group - Quality Instrumentation ...
  • Seite 20: Setting The Temperature Control Mode

    Assembling the stand Setting the temperature control mode Factory setting: PI mode Fig. 6 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 21: Accessories

    Maintenance Accessories www.ika.net Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 22: Error Codes

    Error codes Error code Cause Effect Solution Warning! Only to be carried out by authorised service personnel: Carry out an internal test on the device to check the plug-in connector for the motor (temperature of control sensor) (temperature of safety sensor) Warning! Only to be carried out by authorised service personnel: Carry out an internal test on the device to check the plug-in connector.
  • Seite 23: Technical Data

    Technical Data RCT basic safety control HCT basic safety control Device Motor Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 24 RCT basic safety control HCT basic safety control Base plate Heating Adjustable safety circuit The control accuracy values given were determined using the following set-up: 500 ml water in 600 ml glass beaker, magnetic stirring bar 40, 600 rpm, 50 °C Warranty Artisan Technology Group - Quality Instrumentation ...
  • Seite 25: Consignes De Sécurité

    Sommaire Consignes de sécurité Pour votre protection • Lisez intégralement la notice d'utilisation avant la mise en service et respectez les consignes de sécurité. • • • • • Attention - Magnétisme! • Risques de brûlures! • • Déclaration de conformité CE •...
  • Seite 26 • Les réactions chimiques du polytétrafluoréthlène se produisent par contact avec les métaux alcalins et alcalino-terreux, fon- dus ou dissouts, ainsi que les poudres fines des métaux appartenant au deuxième et au troisième groupe de la classification périodique des élé- ments à...
  • Seite 27: Utilisation Conforme

    Déballage Utilisation conforme Déballage Utilisation Secteur d’utilisation Volume de livraison RCT basic safety control HCT basic safety control Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 28 Utilisation RCT basic safety control HCT basic safety control Mise en service ¢ ¢ Agiter ¢ ¢ Chauffer ¢ ¢ Branchement d’un thermo- ¢ mètre externe (régulation de température ¢ directe dans le milieu) ¢ Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 29: Régler Les Modes D'utilisation

    à travailler! Modifier le mode Test de fonction de inactiver le circuit de sécurité HCT basic safety control Err 25 Réglage d’usine: Mode A Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 30 Régler le mode de régulation de température Montage de la tige de statif Réglage d'usine : mode PI Fig. 6 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 31 Entretien Accessoires www.ika.net Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 32 Messages dʼerreurs Code erreur Cause Conséquence Correction Attention! Destiné au personnel de service autorisé uniquement: Contrôler la connexion à fiche du moteur à l'intérieur de l'appareil (température de la sonde commande) (température de la sonde sécurité) Attention! Destiné au personnel de service autorisé uniquement: Contrôler la connexion à...
  • Seite 33: Caractéristiques Techniques

    Caractéristiques techniques RCT basic safety control HCT basic safety control Appareil Moteur Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 34 RCT basic safety control HCT basic safety control Plateau Chauffage Circuit de sécurité réglable La précision de la régulation indiquée a été établie pour les valeurs suivantes : 500 ml d'eau dans un bécher de 600 ml, bâtonnet magnétique 40, 600 rpm, 50 °C Garantie Artisan Technology Group - Quality Instrumentation ...
  • Seite 35: Indicaciones De Seguridad

    Indicaciones de seguridad Para su protección • Atención: • Lea todas las instrucciones de uso antes de la puesta en marcha y siga siempre las instrucciones de seguridad. • • • • • Atención: Magnetismo! • • • Riesgo de sufrir quemaduras! •...
  • Seite 36 • • • • • > 100 mm > 100 mm Fig. 3 • Para proteger el aparato • • • • • • Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 37: Veiligheidsinstructies

    Veiligheidsinstructies • Voor uw bescherming • Lees de gebruiksaanwijzing helemaal door vóór de inbe- drijfstelling, en neem de veiligheidsvoorschriften in acht. • • • • • • • • Let op - Magnetisme! • niet • Brandgevaar! • • • •...
  • Seite 38 • • Chemische reacties door PTFE ontstaan bij contact met gesmolten of opgeloste alkali- en aardalkalimeta- len, alsmede met fijndelige poeders van metalen uit de 2e en 3e groep van het periodensysteem bij temperaturen van boven de 300 °C - 400 °C. Alleen elementair fluor, chloortrifluoride en alka- limetalen tasten het aan.
  • Seite 39: Norme Di Sicurezza

    Norme di sicurezza Per la Vostra sicurezza • Prima della messa in funzione si raccomanda di leggere le istruzioni per l’uso e di osservare attentamente le norme di sicurezza. • • • • • • • • Attenzione - magnetismo! •...
  • Seite 40 • • • • il PTFE, a contatto con metalli alcalini e alca- lino-terrosi fusi e con polveri fini di metalli del 2° e 3° gruppo del sistema periodico ed esposto a temperature superiori a 300° C - 400° C, può reagire chimicamente. Può essere attaccato solo dal fluoro elementare, dal clorotrifluoroetilene e dai metalli alcalini;...
  • Seite 41: Säkerhetsanvisningar

    Säkerhetsanvisningar Skydda dig själv • Läs hela bruksanvisningen innan du börjar använda appara- ten och observera säkerhetsbestämmelserna. • • • • • • • • inte • Obs – magnetiska fält! • • Risk för brännskador! • • • • •...
  • Seite 42 Skydda instrumentet • • • • • • > 100 mm > 100 mm Fig. 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 43: Sikkerhedshenvisninger

    Sikkerhedshenvisninger Beskyttelsesforanstaltninger • Læs hele driftsvejledningen før ibrugtagningen og vær • opmærksom på sikkerhedsforskrifterne. • • • • • • • ikke • OBS - magnetisme! • • Forbrændingsfare! • • • • • • • • • • • •...
  • Seite 44 • • • • • • > 100 mm > 100 mm Fig. 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 45 Sikkerhetsanvisninger • Personlig sikkerhet • Les hele bruksanvisningen før du begynner å bruke appara- tet, og følg sikkerhetsanvisningene. • • • • • • • Advarsel - magnetisme! • • Fare for forbrenning! • ikke • • • • • •...
  • Seite 46 Beskyttelse av apparatet • • • • • • > 100 mm > 100 mm Fig. 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 47: Turvallisuusohjeet

    Turvallisuusohjeet Oman turvallisuutesi vuoksi • Lue käyttöohje huolella ennen laitteen käyttöä ja noudata kaikkia turvallisuusohjeita. • • • • • • • • ei saa • Huomautus - magneettisuus! • • Palovammojen vaara! • • • • • • • •...
  • Seite 48 Laitteen suojaamiseksi • • • • • • > 100 mm > 100 mm Kuva 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 49: Normas De Segurança

    Normas de segurança Para sua segurança • Antes de ligar o aparelho, recomendamos a leitura atenta das instruções de utilização e a observação cuidadosa das • normas de segurança. • • • • • • • Atenção – magnetismo! • •...
  • Seite 50 • • • • ç Para segurança do aparelho • • • • • • > 100 mm > 100 mm Fig. 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 51: Wskazówki Bezpieczeństwa

    Wskazówki bezpieczeństwa Ochrona u ytkownika • Przed uruchomieniem należy dokładnie przeczytać instrukcję • obsługi i zapoznać się ze wskazówkami bezpieczeństwa. • • • • • • • Uwaga – Pole magnetyczne! • • Niebezpieczeństwo poparzenia! • • • • • •...
  • Seite 52 • • • • Teflon wchod- > 100 mm > 100 mm zi w reakcje chemiczne w zetknięciu z roztopionymi lub rozpuszc- Rys 3 zonymi metalami alkalicznymi i metalami ziem alkalicznych, a także z bardzo rozdrobnionymi proszkami metali grupy 2 i 3 układu okresowego w temperaturze powyżej 300 °C - 400 °C.
  • Seite 53: Bezpečnostní Upozornění

    • Bezpečnostní upozornění K Vaší ochraně • Před uvedením přístroje do provozu si kompletně pročtěte návod k použití a dodržujte pečlivě bezpečnostní pokyny. • • • • • • • • Pozor - magnetismus! • Nepoužívejte • Nebezpečí popálení! • •...
  • Seite 54 • Chemické reakce materiálu PTFE vznikají ve styku s roztavenými nebo rozpuštěnými alkalickými kovy a kovy alkalických zemin a dále s jemnozrnnými prášky kovů z 2. a 3. skupiny periodické soustavy při teplotách vyšších než 300 °C – 400 °C. Materiál napadají jen elementární fluor, chlorid fluorid a alkalické...
  • Seite 55: Biztonsági Utasítások

    Biztonsági utasítások • Az Ön védelme érdekében • Üzembehelyezés előtt gondosan olvassa el a használati uta- sítást, és vegye figyelembe a biztonsági előírásokat. • • • • • • • • Figyelem – Mágnesesség! • • Gyulladásveszély! • Ne • •...
  • Seite 56 • • Ha a teflon 300 °C - 400 °C hőmérséklet felett olvadt vagy oldott alkálifémekkel és alkáli földfé- mekkel, valamint a periódusos rendszer 2. és 3. csoport finoman porított fémeivel kerül kölcsönhatásba, akkor kémiai reakcióba lép velük. Csak az elemi fluor, klór-fluor vegyületek és alkálifémek támadják meg, a halogénezett-szénhidrogének irreverzibilisen duz- zasztják.
  • Seite 57: Varnostna Navodila

    Varnostna navodila Za va o za ito • Pred zagonom v celoti preberite Priročnik za uporabo in • upoštevajte varnostna navodila. • • • • • • • • Pozor, magnetno polje! • • Nevarnost opeklin! • • • • •...
  • Seite 58 rid in alkalne kovine delujejo agresivno, halogenski ogljikovodiki pa povzročajo reverzibilno nabrekanje. Za zaščito naprave • • • • • • > 100 mm > 100 mm Sl. 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 59: Bezpečnostné Pokyny

    Bezpečnostné pokyny Pre vašu ochranu • Prečítajte si celý návod na obsluhu už pred uvedením zaria- denia do prevádzky a rešpektujte bezpečnostné pokyny. • • • • • • • • Pozor – magnetické pole! • neuvádzajte • Nebezpečenstvo popálenia! •...
  • Seite 60 kontakte s roztavenými alebo rozpustenými alkalickými kovmi a kovmi alkalických zemín, a takisto s jemnozrnnými práškovými kovmi 2. a 3. skupiny periodickej sústavy pri teplotách nad 300 °C - 400 °C. Napáda ho iba elementárny fluór, chloridfluorid a alkalické kovy, halogenované uhľovodíky majú reverzibilný napučiavací...
  • Seite 61 Ohutusjuhised Teie kaitseks • Lugege kasutusjuhend enne kasutuselevõttu täielikult läbi ja järgige ohutusnõudeid. • • • • • • • • Tähelepanu – magnetism! • • Põletusoht! • • • • • • • • • • • • • •...
  • Seite 62 leelismetallid reageerivad, halogeensüsivesinikud mõjuvad pai- sutavalt. Seadme kaitseks • • • • • • > 100 mm > 100 mm Joon 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 63: Drošības Norādes

    • Drošības norādes Jūsu drošībai • Pirms iekārtas nodošanas ekspluatācijā uzmanīgi izlasiet lie- tošanas instrukciju un ņemiet vērā drošības norādījumus. • • • • • • • Uzmanību – magnētisms! • • Apdedzināšanās risks! • Nedarbiniet • • • • •...
  • Seite 64 • PTFE ķīmiskās reakcijās iesaistās, nonākot saskarē ar izkausētiem vai izšķīdinātiem sārmu un sārmzemju metāliem, kā arī smalkiem periodiskās sistēmas 2. un 3. grupas metālu pulver- iem temperatūrā virs 300 °C - 400 °C. Ar savienojumu reagē tikai brīvais fluors, hlora fluorīds un sārmu metāli, halogēnogļūdeņraži to atgriezeniski izpleš.
  • Seite 65: Saugos Reikalavimai

    • Saugos reikalavimai Jūsų saugumui • Prieš pradėdami naudotis prietaisu, perskaitykite visą nau- dojimo instrukciją ir laikykitės saugos reikalavimų. • • • • • • • • Dėmesio – magnetizmas! • Nudegimo pavojus! • Nenaudokite • • • • • •...
  • Seite 66 metalų milteliais esant aukštesnei nei 300 °C - 400 °C tempe- ratūrai. Šį termoplastą gali pažeisti elementarusis fluoras, chloro fluoridas ir šarminiai metalai, halogeniniai angliavandeniliai, kurių brinkinantis poveikis yra grįžtamas. Norėdami apsaugoti prietaisą • • • • • • > 100 mm >...
  • Seite 67 Notes Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Seite 68 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
