Product Overview; Charging Instructions - Obsbot Tail 2 Kurzanleitung

Product Overview

Parts Info
01
03
04
01. Camera Lens
02. Tally Light
03. Status Indicator
04. Battery Indicator
05. Cooling Inlet
06. HDMI Port
07. MIC IN Port
08. LINE IN Port
09. RS232 IN Port
10. RS232 OUT Port

Charging Instructions

When using the camera for the first time, please charge it using the included USB-C power
cable to ensure proper functionality.
⚠ It is recommended to use an FCC/CE certified adapter rated 12V/2A or higher and supporting
the USB PD 3.0 protocol.
2
02
06
07
05
08
09 10 12 13
11. Power Button
12. 3G-SDI Port
13. LAN/PoE+ Port
14. USB-C Port
15. Power Input Port
16. Micro SD Card Slot
17. Cooling Outlet
18. UNC 1/4-20 Interface
19. Extension Pin Interface
11
14
16
17
15
18
19
