Pool XXL (11680)
Wasserhöhe max. 35 cm
Befüllbar mit max. 3000 Bälle à Ø 60 mm (6x 12600)
Water level max. 35 cm
Fillable with max. 3000 Balls Ø 60 mm (6x 12600)
325 x 125 x 45 cm
Rohr 35 cm
Tube 35 cm
Raumkupplung 4-armig
Flächenk. 2-armig (90°)
Rohr 75 cm
Elbow Connector
4-Way Connector
12x 00041
4x 00121
56x 00532-00535
Raumkupplung 3-armig
Flächenk. 2-armig (180°)
Bogenrohr
Curved Tube
3-Way Connector
2-Way Connector
6x 00572-00575
20x 00031
8x 00111
4x 10052-10055
1
SCHRAUBEN ZEIGEN
NACH UNTEN
SCREWS POINT DOWN
2
VOR DEM ERSTEN GEBRAUCH
BITTE DIE
SICHERHEITSHINWEISE
SORGFÄLTIG DURCHLESEN!
CAREFULLY READ THE
SAFETY INSTRUCTIONS
BEFORE YOU START ASSEMBLING!
3
2:30
Platte 40 x 40 cm
Poolfolie XXL
Rundtextil
Round Textile
Tube 75 cm
Panel 40 x 40 cm
Pool Liner XXL
2x 00363
Plattenschraube
Panel Screw
2x 00402-00405
1x 10032
8x 00620
VERSION
04.2022
Schlüssel
Key
3x 00675
Rohrschraube
Tube Screw
132x 00612-00615
CAUTION: Carefully read the safety instructions before you start assembling!
QUADRO DER GROSSBAUKASTEN | Am Schilfpark 13, 21029 Hamburg, Germany
blog.quadroshop.com | info@quadroworld.com | www.quadroworld.com
© 1979 – 2024 QUADRO DER GROSSBAUKASTEN. All rights reserved.
Aufbauanleitung
