PCI SUB IW
Product Feature Identi cation
Grille Installed
Subwoofer and Frame Assembly
Subwoofer Assembly
Screws (hex X6)
for mounting
speaker assembly
into frame
Screw terminals for
speaker wires
Frame Assembly
Screws (crosshead X6)
for extending the
mounting clamps
Mounting Clamps (x6)
Product Feature Identi cation
Installation Template
Paint Mask
Quick Start Guide
Back Can Assembly
Wood
Construction
Aperture
Cable Entry for
Speaker Wire
Adjustable
Mounting Brackets
(X4)
