EXPLOSIVE VIEW

• SPOOL GUN
No. Description
1
2
3
4
5
6
7
8
9
10
11
SPOOL GUN
Gun handle
Trigger switch
Block
Cover
Hanger hook
Spool shaft
Bushing resistance rubber
Location bushing
Adjusting nut
Locking screw
Hook
1. Spool cover button
2. Spool cover fixing screw (levo)
3. Spool
4. Hub tension nut
Grasp spool in one hand and turn while adjusting hub tension
nut. When a slight force is needed to turn spool, tension is
set. Do not avertighten.
5. Drive roll Tension Thumbnut
Turn on unit and check drive roll pressure by feeding wire
against a wood board or concrete surface ; wire chould feed
steedily without slipping. Adjust drive roll tension thumbnut
if necessary. Do not overtighten. Turn off unit. Close cover.
6. Gun neck clamping screw
Loosen gun neck clamping screw and remove head tube.
7. Wire feeding speed adjusting knob.
Description
No.
Press arm chaft
24
Bracket
25
Motor and gear box (19 :1)
26
Gas connector
27
Wire feeder assembly
28
29 Conducting bar
Liner assembly
30
O-Ring 7.65x1.78
31
Conductor tube
32
Insulator
33
Diffuser C/W spring
34
EN
