Setting Up Your New E-Scooter - Pure Air5 Bedienungsanleitung

1.2 Setting up your new e-scooter
Your new e-scooter has been thoroughly checked and part-assembled by our
technicians. It's almost ready to ride – just follow these simple set-up instructions
and you'll be ready to go!
1. Set up in box
Keep the e-scooter within the opened box during set
up. This will keep it firmly in place for the next steps.
3. Secure the latch
Lift the latch mechanism until it clips securely into
the stem.
Warning! – Do not ride the scooter if the latch is
loose.
4
2. Raise the stem
Remove any remaining protective packaging from
the e-scooter, then unfold it to its upright position,
making sure the latch is down.
*We strongly recommend you keep the box for the
length of your warranty, in case you need to return
the e-scooter.
4. Lift the handlebar
Lift the handlebar onto the stem ensuring the internal
wires are not trapped and the external brake cable is
not twisted.
Pure Air
5. Fix the handlebar
Rotate the handlebar to align the holes in the stem
with the handlebar. Locate the stem bolts (within
the sealed package), and insert them loosely into the
stem bolt recesses.
7. Fully charge
Charge your e-scooter until the charger status light
changes from red to green
User Manual | EN
5
6. Tighten the bolts
Use the correctly-fitting Allen key supplied to tighten
the bolts. Don't tighten each screw all the way in
one go.
8. Tyre pressure
Check the tyres are inflated to the optimum pressure
of 36 PSI / 2.5 Bar.
Always use the valve extender with your pump. You
will damage the tyre valves if you do not.
5
