Total Controls Apache Benutzerhandbuch Seite 3

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge if they have been given supervision or instruction concer-
ning use of the appliance in a safe way and understand the hazard involved. Children shall not play with the appli-
ance. Cleaning and user maintenance shall not be made by children without supervision. Do not attempt to repair this
product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Do not
submerge into water. Indoor use only.
Features
• 1 Apache KU unit with 51 buttons
• 1 axis
• 1 40x2 character display
Connecting the Unit
1. Connect the unit to your computer via a USB port.
2. Windows will automatically detect the device as "Total Controls Apache KU" and install the necessary drivers.
3. Navigate to Start > Settings > Devices. Verify that "Total Controls Apache KU" appears in the list of connected devices.
Configuring the Display for DCS
1. To enable the display functionality in DCS, install DCS-BIOS.
2. Ensure the unit is connected via the correct COM port as specified in the DCS-BIOS setup.
Adjusting Display Contrast
• Use the rotary switch on the back of the unit to adjust display contrast. A small screwdriver is required for this adjustment.
Rotate until the contrast meets your preference.
Display Brightness Control
• Default Mode:
The display background brightness is controlled by the axis control knob.
• Fixed Brightness:
1. Press and hold Options Buttons (47 & 48).
2. Press Button 2 (8) on the numeric keypad to set fixed brightness.
3. Reset to default brightness mode by pressing Button 1 (7) on the numeric keypad.
Selecting Display Information
Use Options Buttons (47 & 48) in combination with Buttons A, B, C, and D (1-4) to select the information displayed. See page
2 in this manual for reference.
Adjusting Button Brightness
1. Hold Options Buttons (47 & 48).
2. Use the Up and Down Arrows (49 & 51) to increase or decrease brightness of the buttons.
Device Layout
Refer to Page 2 of this manual for the complete layout of the device.
Sleep Mode
The unit will enter a sleep state after 60 minutes of inactivity. In this state, all brightness settings will dim to a low level.
Troubleshooting
If some buttons are not operational on the unit, disconnect the device from your computer and re-connect it again.
Hold Options Buttons (47 & 48) and press button 24 (R) to reset the unit to factory default.
4
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Copyright
© 2025 Total Controls AB. All rights reserved. Windows® is a registered trademark of
Microsoft Corporation in the United States and/or other countries. All other trade-
marks are the property of their respective owners.
Illustrations not binding. Contents, designs and specifications are subject to change
without notice and may vary from one country to another. Made in Sweden.
Contact
Total Controls AB. Älgvägen 41, 428 34, Kållerd, Sweden. www.totalcontrols.eu
Keep this manual for future reference!
!
Small parts. Long cord, strangulation hazard.
Not suitable for children under three years.
Information on Disposal for Users of WEEE
The crossed-out wheeled bin and / or accompanying documents means that used electrical and
electronic equipment (WEEE) should not be mixed with general household waste. For proper treat-
ment, recovery and recycling, please take this product to designated collection points where it will
be accepted free of charge.
Disposing of this product correctly will help save valuable resources and prevent any potential negative effects
on human health and the environment, which could otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with you national legislation.
For disposal in countries outside of the European Union
This symbol is only valid in the European Union (EU). If you wish to discard this product please contact your
local authorities or dealer and ask for the correct method of disposal.
CAUTION
CHOKING HAZARD
5
