HAND CONTROL INSTRUCTION
Usb interface
Diagram
Down arrow button
Up arrow button
Massage key
Heat key
Model No. : LN-604DT-8JR
Function Including :
Lift motor +4 points vibration massage
Tech Specs. :
1.Voltage : AC100-240V DC29V 2A
2.Power : 58W
3.Frequency : 50/60HZ
4.Timer : 15Min / Massage Self-closing
Operation instructions
First, check if the local voltage is consistent with the transformer power supply. If they
match, then plug in to set up the circuit. The top of the hand controller comes with a USB
port to facilitate charging of electronic products such as mobile phones.
The product requires a DC 29V power supply. After powering on, the boot indicator light
will illuminate;
1. Up arrow button: Hold the button to operate. The chair will lower and unfold to the
maximum recline position.
2. Down arrow button: Hold the button to operate. The backrest and footrest will return
and then lift to the top position.
3. "Heat" button: Independent control switch. If users want the product to heat automati-
cally, they can press the heating switch for heating. The maximum heating temperature
is 65°C and it takes about 15 minutes to reach the maximum temperature. The product
has a built-in protective chip, ensuring continuous heating will not exceed the maximum
peak value.
4. "Massage" button: Power On/Off, vibration massage power.
14
