3. Securely fasten the mount to the mounting
surface with the appropriate fasteners.
4. If needed, seal all mounting holes so that no
moisture can leak into the mounting surface.
5. Screw the camera into the mounting bracket.
Ensure that the camera is firmly attached to the
bracket.
6. Connect a 75 ohm coaxial video cable to the
video cable, and connect a 12 VDC power
supply to the power cable.
7. Adjust the camera position and angle as
required.
Specifications
Power supply
Current
Power
consumption
EN 8
All manuals and user guides at all-guides.com
12 VDC
60 mA (IR OFF)
260 mA (IR ON)
3.12 W max.
